395-045 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 45POS 0.100
| Part | Termination Rows | Material - Insulation | Card Type | Termination | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Pitch | Pitch | Number of Positions/Bay/Row | Contact Finish | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Contact Type | Gender | Read Out | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.156 " | 3.96 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Through Hole | Cantilever | Female | Single | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.128 " | 3.25 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Through Hole | Cantilever | Female | Single | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.128 " | 3.25 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Through Hole | Cantilever | Female | Single | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Right Angle Through Hole | Cantilever | Female | Single | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.116 " | 2.95 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Through Hole | Cantilever | Female | Single | Floating Bobbin Flush Mount |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Right Angle Through Hole | Cantilever | Female | Single | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.156 " | 3.96 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Through Hole | Cantilever | Female | Single | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.128 " | 3.25 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Right Angle Through Hole | Cantilever | Female | Single | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.128 " | 3.25 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Through Hole | Cantilever | Female | Single | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 1 | 0.116 " | 2.95 mm | Copper Alloy | 0.1 " | 2.54 mm | 45 | Gold | 45 | -40 C | 105 ░C | Through Hole | Cantilever | Female | Single | Floating Bobbin Top Mount Opening |
