662-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
662 SERIES RIGHT ANGLE DUAL D-SU
| Part | Color | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Number of Rows [custom] | Connector Style | Flange Feature | Contact Type | Material Flammability Rating | Features | Shell Material, Finish | Mounting Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Connector Type | Backset Spacing | Backset Spacing | Number of Positions | Number of Positions | Termination | Flange Feature | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | 4-40 Mating Side Female Screwlock | Signal | UL94 V-0 | Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | 0.38 µm | 15 µin | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | ||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | 4-40 Mating Side Female Screwlock | Signal | UL94 V-0 | Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | 0.38 µm | 15 µin | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | ||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | Housing/Shell | Signal | UL94 V-0 | Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | 0.38 µm | 15 µin | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | 4-40 | |
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | 4-40 Mating Side Female Screwlock | Signal | UL94 V-0 | Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | Flash | |||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | Housing/Shell (Unthreaded) | Signal | UL94 V-0 | Board Lock Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | 0.38 µm | 15 µin | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | ||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | Housing/Shell (M3) | Signal | UL94 V-0 | Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | 0.38 µm | 15 µin | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | ||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | Housing/Shell (Unthreaded) | Signal | UL94 V-0 | Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | 0.76 Ám | 30 Áin | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | ||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | Housing/Shell | Signal | UL94 V-0 | Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | 4-40 | Flash | ||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | 4-40 Mating Side Female Screwlock | Signal | UL94 V-0 | Board Lock Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder | Flash | |||
 EDAC Inc. | Black | Polyester Thermoplastic | -55 C | 85 °C | 3 A | 2 | D-Sub - Stacked | Housing/Shell (M3) | Signal | UL94 V-0 | Board Lock Mounting Brackets Shielded | Nickel Plated Steel | Right Angle Through Hole | 2 | 2 | 0.38 µm | 15 µin | Gold | Receptacle Female Sockets | 8.08 mm | 0.318 " | 15 | 15 | Solder |
