RC-700112 Series

RELAY 70A FORM_C 12V RES_BRKT

Catalog

RELAY 70A FORM_C 12V RES_BRKT

Part	Contact Material	Must Operate Voltage	Coil Voltage	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Coil Type	Must Release Voltage	Features	Mounting Type	Contact Form	Contact Rating (Current)
LITTELFUSE RC-700112-RN	Silver Alloy	7.8 VDC	12 VDC	Plug In	85 °C	-40 C	Non Latching	1.2 VDC	Resistor	Chassis Mount	SPDT (1 Form C)	70 A
LITTELFUSE RC-700112-NN	Silver Alloy	7.8 VDC	12 VDC	Plug In	85 °C	-40 C	Non Latching	1.2 VDC		Chassis Mount	SPDT (1 Form C)	70 A

Catalog

RELAY 70A FORM_C 12V RES_BRKT

Description

The ISO Power Relays Series offers a variety of automotive plug-in relays featuring a 12 V isolated coil. Adhering to the ISO Maxi Relay form factor, these power relays plug into existing boxes along with fuses or other components (sold separately), helping you tailor your vehicle's power distribution box for the capability you need, such as lighting, starting, horn, heating and cooling, or fan control. This model (RC-700112-NN) is a Form C relay with single-pole, double-throw (SPDT) circuitry and features no suppression.
