BL620 Series
Manufacturer: Ezurio LLC
Beta
⌘K
RF TXRX MOD BLUETOOTH CHIP SMD
| Part | RF Family/Standard | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Max] | Voltage - Supply [Min] | Power - Output | Package / Case | Data Rate | Current - Receiving | Serial Interfaces | Utilized IC / Part | Protocol | Frequency | Antenna Type | Current - Transmitting | Sensitivity | Mounting Type | Modulation or Protocol | Frequency [Max] | Frequency [Min] | Function | Applications | Interface | Data Rate (Max) [Max] | Antenna Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Ezurio LLC | Bluetooth | 85 °C | -40 C | 3.6 V | 1.8 V | 4 dBm | Module | 1 Mbps | 10.5 mA | I2C SPI UART | nRF51822 | Bluetooth v4.0 | 2.4 GHz | Chip Integrated | 10.5 mA | -91 dBm | Surface Mount | ||||||||
 Ezurio LLC | 3.6 V | 1.8 V | 4 dBm | -91 dBm | Bluetooth v4.0 Low Energy (BLE) | 2.48 GHz | 2.4 GHz | Transceiver | General Purpose | USB | 1 Mbps | ||||||||||||||
 Ezurio LLC | Bluetooth | 85 °C | -40 C | 3.6 V | 1.8 V | 4 dBm | Module | 1 Mbps | 10.5 mA | I2C SPI UART | nRF51822 | Bluetooth v4.0 | 2.4 GHz | I-PEX MHF4 | 10.5 mA | -91 dBm | Surface Mount | ||||||||
 Ezurio LLC | Bluetooth | 85 °C | -40 C | 3.6 V | 1.8 V | 4 dBm | Module | 1 Mbps | 10.5 mA | I2C SPI UART | nRF51822 | Bluetooth v4.0 | 2.4 GHz | Antenna Not Included | 10.5 mA | -91 dBm | Surface Mount | ||||||||
Ezurio LLC | Bluetooth | 85 °C | -40 C | 3.6 V | 1.8 V | 4 dBm | Module | 1 Mbps | 10.5 mA | I2C SPI UART | nRF51822 | Bluetooth v4.0 | 2.4 GHz | Chip Integrated | 10.5 mA | -91 dBm | Surface Mount | ||||||||
Ezurio LLC | 3.6 V | 1.8 V | 4 dBm | -91 dBm | Bluetooth v4.0 Low Energy (BLE) | 2.48 GHz | 2.4 GHz | Transceiver | General Purpose | USB | 1 Mbps | ||||||||||||||
Ezurio LLC | Bluetooth | 85 °C | -40 C | 3.6 V | 1.8 V | 4 dBm | Module | 1 Mbps | 10.5 mA | I2C SPI UART | nRF51822 | Bluetooth v4.0 | 2.4 GHz | Antenna Not Included | 10.5 mA | -91 dBm | Surface Mount | ||||||||
Ezurio LLC | Bluetooth | 85 °C | -40 C | 3.6 V | 1.8 V | 4 dBm | Module | 1 Mbps | 10.5 mA | I2C SPI UART | nRF51822 | Bluetooth v4.0 | 2.4 GHz | I-PEX MHF4 | 10.5 mA | -91 dBm | Surface Mount |
