846-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 30POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Color | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Termination | Contact Finish Thickness | Contact Finish Thickness | Read Out | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Contact Type | Mounting Type | Number of Positions | Gender | Card Type | Number of Positions/Bay/Row | Contact Finish | Flange Feature | Features | Termination Rows | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | Dual | 2 | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Through Hole | 30 | Female | Non Specified - Dual Edge | 15 | Gold | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Dual | 2 | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Board Edge Straddle Mount | 30 | Female | Non Specified - Dual Edge | 15 | Gold | M3 Threaded Insert Top Mount Opening | Card Extender | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | Single | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Through Hole | 30 | Female | Non Specified - Single Edge | 30 | Gold | Side Mount Opening Unthreaded | 1 | 0.128 " | 3.25 mm | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | Dual | 2 | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Through Hole | 30 | Female | Non Specified - Dual Edge | 15 | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | Single | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Through Hole | 30 | Female | Non Specified - Single Edge | 30 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | Single | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Right Angle Through Hole | 30 | Female | Non Specified - Single Edge | 30 | Gold | 1 | 0.128 " | 3.25 mm | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Dual | 2 | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Board Edge Straddle Mount | 30 | Female | Non Specified - Dual Edge | 15 | Gold | 4-40 Threaded Insert Top Mount Opening | Card Extender | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | Dual | 2 | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Through Hole | 30 | Female | Non Specified - Dual Edge | 15 | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | Dual | 2 | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Through Hole | 30 | Female | Non Specified - Dual Edge | 15 | Gold | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | Dual | 2 | 125 °C | -40 C | 3.18 mm | 0.125 in | Cantilever | Through Hole | 30 | Female | Non Specified - Dual Edge | 15 | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm |
