PFRA.050 Series

Catalog

PTC RESET FUSE 60V 500MA RADIAL

Part	Approval Agency	Current - Trip (It)	Size / Dimension [diameter]	Size / Dimension [z]	Size / Dimension [diameter]	Size / Dimension [z]	Package / Case	Lead Spacing	Lead Spacing	Type	Resistance - Post Trip (R1) (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Mounting Type	Resistance - Initial (Ri) (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Time to Trip	Voltage - Max [Max]	Current - Hold (Ih) (Max) [Max]	Current - Max [Max]
SCHURTER Inc. PFRA.050.2	cURus TUV	1 A	7.9 mm	0.122 in	0.311 in	3.1 mm	Disc Radial	0.201 in	5.1 mm	Polymeric	1.17 Ohms	0.539 in	13.7 mm	Through Hole	410 mOhms	85 °C	-40 C	4 s	60 V	500 mA	40 A
