833-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 15POS 0.156
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Number of Rows | Read Out | Contact Type | Color | Number of Positions/Bay/Row | Contact Finish | Number of Positions | Contact Material | Card Type | Gender | Pitch | Pitch | Termination | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Solder Eyelet(s) | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Solder | 0.25 Ám | 10 Áin | 125 °C | -40 C | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Wire Wrap | 0.25 Ám | 10 Áin | 125 °C | -40 C | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Right Angle Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Solder | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Solder | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Wire Wrap | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Solder | 0.25 Ám | 10 Áin | 125 °C | -40 C | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Wire Wrap | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Solder | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | Through Hole | 1 | Single | Cantilever | Green | 15 | Gold | 15 | Copper Alloy | Non Specified - Single Edge | Female | 3.96 mm | 0.156 in | Wire Wrap | 0.25 Ám | 10 Áin | 125 °C | -40 C |
