RPYS002 Series
Manufacturer: Carlo Gavazzi Inc.
Beta
⌘K
RELAY GEN PURPOSE DPDT 5A 12V
| Part | Coil Resistance | Approval Agency | Coil Type | Contact Material | Load - Max Switching | Operate Time | Operating Temperature [Max] | Operating Temperature [Min] | Contact Rating (Current) | Termination Style | Coil Current | Switching Voltage [Max] | Coil Voltage | Must Operate Voltage | Relay Type | Release Time | Must Release Voltage | Contact Form | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Carlo Gavazzi Inc. | 270 Ohms | CE UL | Non Latching | Silver Alloy | 150 W 1250 VA | 20 ms | 55 °C | -40 C | 5 A | Plug In 6 Pin | 44.4 mA | 30 VDC 250 VAC | 12 VDC | 9 VDC | General Purpose | 10 ms | 1.2 VDC | DPDT (2 Form C) | Socketable |
