1811A Series
Manufacturer: Belden Inc.
Beta
⌘K
8 #14 PVC PVC
| Part | Conductor Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Wire Gauge | Conductor Strand [custom] | Conductor Strand | Voltage | Jacket (Insulation) Material | Length | Length | Number of Conductors [custom] | Conductor Insulation | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Operating Temperature [Min] | Operating Temperature [Max] | Usage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Bare | 0.515 in | 13.08 mm | Black | 14.5 AWG | 104 | 34 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft | 8 | Poly-Vinyl Chloride (PVC) | 1.016 mm | 0.04 in | Speaker | -20 ░C | 60 °C | Audio |
