845-068 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 68POS 0.100
| Part | Card Thickness [Max] | Card Thickness [Min] | Termination Rows [custom] | Read Out | Contact Finish Thickness | Contact Finish Thickness | Color | Number of Positions/Bay/Row | Pitch | Pitch | Termination | Mounting Type | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Gender | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] | Material - Insulation | Number of Positions | Number of Rows [custom] | Contact Type | Features | Flange Feature | Number of Rows | Termination Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.25 Ám | 10 Áin | Green | 34 | 0.1 " | 2.54 mm | Solder Eyelet(s) | Through Hole | Gold | 125 °C | -40 C | Non Specified - Dual Edge | Female | Copper Alloy | 0.156 " | 3.96 mm | Diallyl Phthalate (DAP) | 68 positions | 2 | Cantilever | ||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.25 Ám | 10 Áin | Green | 34 | 0.1 " | 2.54 mm | Solder | Board Edge Straddle Mount | Gold | 125 °C | -40 C | Non Specified - Dual Edge | Female | Copper Alloy | 0.156 " | 3.96 mm | Diallyl Phthalate (DAP) | 68 positions | 2 | Cantilever | Card Extender | Flush Mount Top Opening Unthreaded | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 0.25 Ám | 10 Áin | Green | 68 | 0.1 " | 2.54 mm | Wire Wrap | Through Hole | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Copper Alloy | 0.128 " | 3.25 mm | Diallyl Phthalate (DAP) | 68 positions | Cantilever | Flush Mount Side Opening Unthreaded | 1 | 1 | |||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 0.25 Ám | 10 Áin | Green | 68 | 0.1 " | 2.54 mm | Solder | Right Angle Through Hole | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Copper Alloy | 0.116 " | 2.95 mm | Diallyl Phthalate (DAP) | 68 positions | Cantilever | Floating Bobbin Top Mount Opening | 1 | 1 | |||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.25 Ám | 10 Áin | Green | 34 | 0.1 " | 2.54 mm | Solder | Right Angle Through Hole | Gold | 125 °C | -40 C | Non Specified - Dual Edge | Female | Copper Alloy | 0.128 " | 3.25 mm | Diallyl Phthalate (DAP) | 68 positions | 2 | Cantilever | Side Mount Opening Unthreaded | |||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.25 Ám | 10 Áin | Green | 34 | 0.1 " | 2.54 mm | Solder | Board Edge Straddle Mount | Gold | 125 °C | -40 C | Non Specified - Dual Edge | Female | Copper Alloy | 0.128 " | 3.25 mm | Diallyl Phthalate (DAP) | 68 positions | 2 | Cantilever | Card Extender | Side Mount Opening Unthreaded | ||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 0.25 Ám | 10 Áin | Green | 68 | 0.1 " | 2.54 mm | Solder | Through Hole | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Copper Alloy | 0.128 " | 3.25 mm | Diallyl Phthalate (DAP) | 68 positions | Cantilever | 1 | 1 | ||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 0.25 Ám | 10 Áin | Green | 68 | 0.1 " | 2.54 mm | Wire Wrap | Through Hole | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Copper Alloy | Diallyl Phthalate (DAP) | 68 positions | Cantilever | 4-40 Threaded Insert Top Mount Opening | 1 | 1 | |||||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.25 Ám | 10 Áin | Green | 34 | 0.1 " | 2.54 mm | Solder | Board Edge Straddle Mount | Gold | 125 °C | -40 C | Non Specified - Dual Edge | Female | Copper Alloy | 0.156 " | 3.96 mm | Diallyl Phthalate (DAP) | 68 positions | 2 | Cantilever | Card Extender | |||
 EDAC Inc. | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.25 Ám | 10 Áin | Green | 34 | 0.1 " | 2.54 mm | Wire Wrap | Through Hole | Gold | 125 °C | -40 C | Non Specified - Dual Edge | Female | Copper Alloy | Diallyl Phthalate (DAP) | 68 positions | 2 | Cantilever | M3 Threaded Insert Top Mount Opening |
