LA-101 Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
DISPLAY 7-SEG 1" SGL GREEN 20DIP
| Part | Digit/Alpha Size | Digit/Alpha Size | Power Dissipation (Max) [Max] | Common Pin | Wavelength - Peak | Display Type | Number of Characters | Millicandela Rating | Color | Voltage - Forward (Vf) (Typ) | Package / Case | Package / Case | Package / Case | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Current - Test |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 1 in | 25.4 mm | 640 mW | Common Cathode | 563 nm | 7-Segment | 1 | 16 mcd | Green | 4.2 V | 1.2 in | 20-DIP | 30.5 mm | 24 mm | 34 mm | 1.339 in | 0.945 " | 10.5 mm | 0.413 in | 10 mA |
 Rohm Semiconductor | 1 in | 25.4 mm | 640 mW | Common Anode | 650 nm | 7-Segment | 1 | 10 mcd | Red | 4 V | 1.2 in | 20-DIP | 30.5 mm | 24 mm | 34 mm | 1.339 in | 0.945 " | 10.5 mm | 0.413 in | 10 mA |
