106 PED-ST Series
Manufacturer: Vishay Dale
Beta
⌘K
ELECTROLYTIC CAPACITOR, 106 PED-ST SERIES, 10000 F, +30%, -10%, 63 V, 50 MM, 8 OHM ROHS COMPLIANT: YES
| Part | Size / Dimension Diameter | Polarization | Operating Temperature (Min) | Operating Temperature (Max) | Voltage - Rated | Ripple Current | ESR (Equivalent Series Resistance) | Capacitance | Impedance | Lifetime | Package / Case | Tolerance (Positive) | Tolerance (Negative) | Mounting Type | Lead Spacing | Applications | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay Dale | 1.969 in | Polar | -40 °C | 85 °C | 63 V | 17 A | 12 mOhm | 10000 µF | 9 mOhm | 20000 Hrs | Can - Screw Terminals Radial | 30 % | 10 % | Chassis Mount | 0.874 in | General Purpose | 3.535 in |
 Vishay Dale | 1.378 in | Polar | -40 °C | 85 °C | 25 VAC | 7.7 A | 40 mOhm | 10000 µF | 31 mOhm | 20000 Hrs | Can - Screw Terminals Radial | 30 % | 10 % | Chassis Mount | 0.504 in | General Purpose | 3.535 in |
