1462039 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY TELECOM DPDT 2A 5V
| Part | Coil Resistance | Contact Material | Load - Max Switching | Must Operate Voltage | Seal Rating | Mounting Type | Operate Time | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Must Release Voltage | Coil Voltage | Contact Rating (Current) | Coil Type | Contact Form | Coil Current | Switching Voltage [Max] | Relay Type | Release Time | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 234 Ohms | Gold (Au) Palladium (Pd) Ruthenium (Ru) | 440 W 500 VA | 4 VDC | Sealed - Hermetically | Surface Mount | 3 ms | Gull Wing | 85 °C | -40 C | 0.5 VDC | 5 VDC | 2 A | Non Latching | DPDT (2 Form C) | 0.02 A | 220 VDC 250 VAC | Telecom | 3 ms | |
 TE Connectivity AMP Connectors | 203 Ohms | Gold (Au) Silver Nickel (AgNi) | 60 W 62.5 VA | 3.38 VDC | Sealed - Hermetically | Surface Mount | 3 ms | PC Pin | 85 °C | -40 C | 0.45 VDC | 4.5 VDC | 5 A | Latching Single Coil | DPDT (2 Form C) | 22.2 mA | 220 VDC 250 VAC | Telecom | 3 ms | UR VDE |
 TE Connectivity AMP Connectors | 1030 Ohms | Gold (Au) Silver Nickel (AgNi) | 60 W 62.5 VA | 9 VDC | Sealed - Hermetically | Surface Mount | 3 ms | Gull Wing | 85 °C | -40 C | 1.2 VDC | 12 VDC | 5 A | Non Latching | DPDT (2 Form C) | 11.7 mA | 220 VDC 250 VAC | Telecom | 3 ms | UR VDE |
 TE Connectivity AMP Connectors | 500 Ohms | Gold (Au) Palladium (Pd) Ruthenium (Ru) | 440 W 500 VA | 4.25 VDC | Sealed - Hermetically | Through Hole | 3 ms | PC Pin | 85 °C | -40 C | 0.5 VDC | 5 VDC | 2 A | Non Latching | DPDT (2 Form C) | 10 mA | 220 VDC 250 VAC | Telecom | 3 ms | |
TE Connectivity AMP Connectors | 1030 Ohms | Gold (Au) Silver Nickel (AgNi) | 60 W 62.5 VA | 9 VDC | Sealed - Hermetically | Surface Mount | 3 ms | Gull Wing | 85 °C | -40 C | 1.2 VDC | 12 VDC | 5 A | Non Latching | DPDT (2 Form C) | 11.6 mA | 220 VDC 250 VAC | Telecom | 3 ms | UR VDE |
TE Connectivity AMP Connectors | 1.029 kOhms | Gold (Au) Palladium (Pd) Ruthenium (Ru) | 440 W 500 VA | 9 VDC | Sealed - Hermetically | Surface Mount | 3 ms | J Lead | 85 °C | -40 C | 1.2 VDC | 12 VDC | 2 A | Non Latching | DPDT (2 Form C) | 11.7 mA | 220 VDC 250 VAC | Telecom | 3 ms | |
 TE Connectivity AMP Connectors | 1030 Ohms | Gold (Au) Silver Nickel (AgNi) | 60 W 62.5 VA | 9 VDC | Sealed - Hermetically | Through Hole | 3 ms | PC Pin | 85 °C | -40 C | 1.2 VDC | 4.5 VDC 12 VDC | 5 A | Non Latching | DPDT (2 Form C) | 11.7 mA | 220 VDC 250 VAC | Telecom | 3 ms | UR VDE |
TE Connectivity AMP Connectors | 179 Ohms | Gold (Au) Palladium (Pd) Ruthenium (Ru) | 440 W 500 VA | 3.75 VDC | Sealed - Hermetically | Through Hole | 3 ms | PC Pin | 85 °C | -40 C | 0.5 VDC | 5 VDC | 2 A | Non Latching | DPDT (2 Form C) | 28 mA | 220 VDC 250 VAC | Telecom | 3 ms | |
TE Connectivity AMP Connectors | ||||||||||||||||||||
 TE Connectivity AMP Connectors | 145 Ohms | Gold (Au) Palladium (Pd) Ruthenium (Ru) | 440 W 500 VA | 3.38 VDC | Sealed - Hermetically | Through Hole | 3 ms | PC Pin | 85 °C | -40 C | 0.45 VDC | 4.5 VDC | 2 A | Non Latching | DPDT (2 Form C) | 31 mA | 220 VDC 250 VAC | Telecom | 5 ms |
