PBW30F Series

Catalog

AC/DC POWER SUPPLY DUAL-OUT -15V/15V 4A/1A 30W

Part	Current - Output 1	Power (Watts)	Current - Output 2	Approval Agency	Type	Voltage - Output 1	Features	Number of Outputs	Mounting Type	Applications	Voltage - Output 2	Efficiency	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]
Cosel USA, Inc. PBW30F-15	1 A	30 Watts	1.4 A	CE cURus TUV	Enclosed	15 V	DC Input Capable Universal Input	2	Chassis Mount	ITE (Commercial)	-15 V	79 %
Cosel USA, Inc. PBW30F-5-C	1.5 A		2 A	CE cURus TUV	Open Frame	5 V		2	Chassis Mount	ITE (Commercial)	-5 V	75 %	31 mm	3.07 in	78 mm	103.1 mm	1.22 in	4.06 in	3000 V	71 °C	-10 °C
Cosel USA, Inc. PBW30F-12-EJ	1.3 A		1.7 A	CE cURus TUV	Open Frame	12 V		2	Chassis Mount	ITE (Commercial)	-12 V	81 %	31 mm	3.07 in	78 mm	103.1 mm	1.22 in	4.06 in	3000 V	71 °C	-10 °C
Cosel USA, Inc. PBW30F-12-C	1.3 A		1.7 A	CE cURus TUV	Open Frame	12 V		2	Chassis Mount	ITE (Commercial)	-12 V	81 %	31 mm	3.07 in	78 mm	103.1 mm	1.22 in	4.06 in	3000 V	71 °C	-10 °C
Cosel USA, Inc. PBW30F-15-CJN	1 A		1.4 A	CE cURus TUV	Enclosed	15 V		2	Chassis Mount	ITE (Commercial)	-15 V	79 %	31 mm	3.07 in	78 mm	103.1 mm	1.22 in	4.06 in	3000 V	71 °C	-10 °C
Cosel USA, Inc. PBW30F-12-CN1	1.3 A		1.7 A	CE cURus TUV	Open Frame	12 V		2	Chassis Mount	ITE (Commercial)	-12 V	81 %	31 mm	3.07 in	78 mm	103.1 mm	1.22 in	4.06 in	3000 V	71 °C	-10 °C
Cosel USA, Inc. PBW30F-15-N	1 A	30 Watts	1.4 A	CE cURus TUV	Enclosed	15 V	DC Input Capable Universal Input	2	Chassis Mount	ITE (Commercial)	-15 V	79 %
Cosel USA, Inc. PBW30F-5	1.5 A	30 Watts	2 A	CE cURus TUV	Enclosed	5 V	DC Input Capable Universal Input	2	Chassis Mount	ITE (Commercial)	-5 V	75 %
Cosel USA, Inc. PBW30F-5-T	1.5 A		2 A	CE cURus TUV	Open Frame	5 V		2	Chassis Mount	ITE (Commercial)	-5 V	75 %	31 mm	3.07 in	78 mm	103.1 mm	1.22 in	4.06 in	3000 V	71 °C	-10 °C
Cosel USA, Inc. PBW30F-5-N1	1.5 A		2 A	CE cURus TUV	Open Frame	5 V		2	Chassis Mount	ITE (Commercial)	-5 V	75 %	31 mm	3.07 in	78 mm	103.1 mm	1.22 in	4.06 in	3000 V	71 °C	-10 °C
