CI2204P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
4 POS 2.50MM (.098) WIRE TO BOAR
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Style | Fastening Type | Contact Length - Post | Contact Length - Post | Insulation Material | Pitch - Mating | Pitch - Mating | Shrouding | Number of Positions Loaded | Contact Type | Connector Type | Material Flammability Rating | Number of Rows | Number of Positions | Contact Finish - Post | Current Rating (Amps) | Mounting Type | Contact Shape | Termination | Insulation Height | Insulation Height | Insulation Color | Voltage Rating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | 105 ░C | -25 °C | Brass | Board to Cable/Wire | Detent Lock | 0.13 " | 3.3 mm | Nylon 6/6 Polyamide (PA66) | 2.5 mm | 0.098 in | Shrouded - 4 Wall | All | Male Pin | Header | UL94 V-0 | 1 | 4 | Tin | 3 A | Through Hole | Square | Kinked Pin Solder | 0.276 in | 7 mm | Natural | 250 VAC | 120 µin | 3.05 µm |
