CP-01420 Series
Manufacturer: Cvilux USA
Beta
⌘K
4.20MM 20 POS DUAL ROWS RIGHT AN
| Part | Number of Rows [custom] | Style | Pitch - Mating | Pitch - Mating | Contact Length - Post | Contact Length - Post | Row Spacing - Mating | Row Spacing - Mating | Voltage Rating | Current Rating (Amps) | Contact Material | Contact Finish - Post | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Fastening Type | Connector Type | Contact Shape | Material Flammability Rating | Insulation Color | Termination | Insulation Height | Insulation Height | Number of Positions | Insulation Material | Contact Type | Shrouding | Number of Positions Loaded | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 2 | Board to Cable/Wire | 0.165 in | 4.2 mm | 0.138 in | 3.5 mm | 0.165 in | 4.2 mm | 600 VAC | 9 A | Brass | Tin | 85 °C | -25 °C | Right Angle Through Hole | Locking Ramp | Header | Square | UL94 V-2 | Natural | Solder | 10 mm | 0.394 " | 20 | Nylon 6/6 Polyamide (PA66) | Male Pin | Shrouded - 4 Wall | All | Board Lock |
