395-088 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Material | Read Out | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Pitch | Pitch | Color | Termination | Contact Type | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Card Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Solder | Cantilever | 88 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Through Hole | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Solder | Cantilever | 88 | M3 Threaded Insert Top Mount Opening | Right Angle Through Hole | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Solder | Cantilever | 88 | 4-40 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Card Extender Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Solder | Cantilever | 88 | 4-40 Threaded Insert Top Mount Opening | Through Hole | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Wire Wrap | Cantilever | 88 | M3 Threaded Insert Top Mount Opening | Through Hole | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Wire Wrap | Cantilever | 88 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Solder | Cantilever | 88 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Board Edge Straddle Mount | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Wire Wrap | Cantilever | 88 | 0.128 " | 3.25 mm | Through Hole | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Wire Wrap | Cantilever | 88 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Female | -40 C | 105 ░C | 44 | 0.1 " | 2.54 mm | Black | Solder Eyelet(s) | Cantilever | 88 | M3 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | Gold | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Card Extender |
