PXE30 Series

Catalog

ISOLATED THROUGH HOLE DC/DC CONVERTER, ITE, 4:1, 30 W, 2 OUTPUT, 12 V, 1.25 A

Part	Package / Case	Features	Voltage - Output 1	Power (Watts)	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Voltage - Isolation	Mounting Type	Voltage - Output 2	Voltage - Input (Min) [Min]	Type	Applications	Number of Outputs	Current - Output (Max)	Voltage - Input (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Efficiency	Current - Output (Max) [Max]
TDK Corporation PXE30-48WD12	8-DIP Module 7 Leads	OCP OVP Remote On/Off SCP	12 V	30 Watts	2 in	0.4 "	10.2 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole	-12 V	18 V	Isolated Module	ITE (Commercial)	2	1.25 A	75 V	-40 C	100 °C
TDK Corporation PXE30-24WS3P3	8-DIP Module 6 Leads	OCP OVP Remote On/Off SCP	3.3 V	30 Watts	2 in	0.4 "	10.2 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole		10 VDC	Isolated Module	ITE (Commercial)	1			-40 C	100 °C	87 %	6 A
TDK Corporation PXE30-24D12	8-DIP Module 7 Leads	OCP OVP Remote On/Off SCP	12 V	30 Watts	2 in	0.4 "	8.6 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole	-12 V	18 V	Isolated Module	ITE (Commercial)	2	1.25 A	36 V	-40 C	100 °C	88 %
TDK Corporation PXE30-48S12	8-DIP Module 6 Leads	OCP OVP Remote On/Off SCP	12 V	30 Watts	2 in	0.4 "	8.6 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole		36 V	Isolated Module	ITE (Commercial)	1		75 V	-40 C	100 °C	90 %	2.5 A
TDK Corporation PXE30-48S15	8-DIP Module 6 Leads	OCP OVP Remote On/Off SCP	15 V	30 Watts	2 in	0.4 "	8.6 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole		36 V	Isolated Module	ITE (Commercial)	1		75 V	-40 C	100 °C	90 %	2 A
TDK Corporation PXE30-24S12	8-DIP Module 6 Leads	OCP OVP Remote On/Off SCP	12 V	30 Watts	2 in	0.4 "	8.6 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole		18 V	Isolated Module	ITE (Commercial)	1		36 V	-40 C	100 °C	89 %	2.5 A
TDK Corporation PXE30-24S05	8-DIP Module 6 Leads	OCP OVP Remote On/Off SCP	5 V	30 Watts	2 in	0.4 "	8.6 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole		18 V	Isolated Module	ITE (Commercial)	1		36 V	-40 C	100 °C	88 %	6 A
TDK Corporation PXE30-12D15	8-DIP Module 7 Leads	OCP OVP Remote On/Off SCP	15 V	30 Watts	2 in	0.4 "	8.6 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole	-15 V	9 V	Isolated Module	ITE (Commercial)	2	1 A	18 V	-40 C	100 °C	87 %
TDK Corporation PXE30-48WS3P3	8-DIP Module 6 Leads	OCP OVP Remote On/Off SCP	3.3 V	30 Watts	2 in	0.4 "	10.2 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole		18 V	Isolated Module	ITE (Commercial)	1		75 V	-40 C	100 °C	87 %	6 A
TDK Corporation PXE30-24WD12	8-DIP Module 7 Leads	OCP OVP Remote On/Off SCP	12 V	30 Watts	2 in	0.4 "	10.2 mm	50.8 mm	1.6 in	40.6 mm	1.6 kV	Through Hole	-12 V	9 V	Isolated Module	ITE (Commercial)	2	1.25 A	36 V	-40 C	100 °C
