2EDL8123 Series
Manufacturer: INFINEON
Beta
⌘K
2EDL8123G3C IS A HIGH-SIDE AND LOW-SIDE DRIVER DESIGNED FOR ADVANCED SWITCHING CONVERTERS SUCH AS IN TELECOM AND DATACOM APPLICATIONS.
| Part | Gate Type | Rise / Fall Time (Typ) | Voltage - Supply [Min] | Voltage - Supply [Max] | High Side Voltage - Max (Bootstrap) [Max] | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Drivers | Input Type | Supplier Device Package | Current - Peak Output (Source, Sink) [custom] | Current - Peak Output (Source, Sink) [custom] | Driven Configuration | Package / Case | Channel Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | MOSFET (N-Channel) N-Channel MOSFET | 45 ns | 8 V | 17 V | 120 V | Surface Mount | -40 C | 125 °C | 2 | Non-Inverting | PG-VSON-10-4 | 5 A | 3 A | High-Side and Low-Side | 10-VFDFN Exposed Pad | Independent |
 INFINEON | MOSFET (N-Channel) N-Channel MOSFET | 45 ns | 8 V | 17 V | 90 V | Surface Mount | -40 C | 125 °C | 2 | Non-Inverting | PG-VDSON-8-4 | 3 A | 3 A | High-Side and Low-Side | 8-VDFN Exposed Pad | Independent |
