179DTNH Series
Manufacturer: Belden Inc.
Beta
⌘K
#28H PE/GIFPE SH PPO
| Part | VoP, Velocity of Propagation | Shield Coverage | Shield Material | Conductor Material | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | Jacket Color | Cable Group | Conductor Strand | Cable Type | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter | Shield Type | Jacket (Insulation) Material | Length [x] | Length [x] | Impedance | Usage | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 79 | 95 % 100 % | Aluminum Copper Tinned | Copper Bare | Foam Polyethylene (FPE) | 75 ░C | -30 ░C | 0.012 in | 0.3 mm | Yellow | RG-179 | Solid | Coaxial | 0.106 in | 2.69 mm | Braid Foil | Low Smoke Polyphenylene Oxide (LSPPO) | 304.8 m | 1000 ft | 75 Ohms | Datacom Network | 28 AWG |
Belden Inc. | 79 | 95 % 100 % | Aluminum Copper Tinned | Copper Bare | Foam Polyethylene (FPE) | 75 ░C | -30 ░C | 0.012 in | 0.3 mm | Violet | RG-179 | Solid | Coaxial | 0.106 in | 2.69 mm | Braid Foil | Low Smoke Polyphenylene Oxide (LSPPO) | 304.8 m | 1000 ft | 75 Ohms | Datacom Network | 28 AWG |
Belden Inc. | 79 | 95 % 100 % | Aluminum Copper Tinned | Copper Bare | Foam Polyethylene (FPE) | 75 ░C | -30 ░C | 0.012 in | 0.3 mm | Blue | RG-179 | Solid | Coaxial | 0.106 in | 2.69 mm | Braid Foil | Low Smoke Polyphenylene Oxide (LSPPO) | 304.8 m | 1000 ft | 75 Ohms | Datacom Network | 28 AWG |
