310-93 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN RCPT 36POS 0.1 GOLD PCB
| Part | Number of Rows | Contact Length - Post | Contact Length - Post | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Insulation Material | Voltage Rating | Voltage Rating | Material Flammability Rating | Contact Finish - Mating | Mounting Type | Fastening Type | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Color | Current Rating (Amps) | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Connector Type | Termination | Contact Shape | Contact Type | Contact Material | Insulation Height | Insulation Height | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | 1 | 0.125 in | 3.18 mm | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Through Hole | Push-Pull | 36 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | |||
 Mill-Max Manufacturing Corp. | 1 | 0.125 in | 3.18 mm | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Through Hole | Push-Pull | 14 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | |||
Mill-Max Manufacturing Corp. | 1 | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Surface Mount | Push-Pull | 19 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | 5.6 mm | 0.22 in | |||
Mill-Max Manufacturing Corp. | 1 | 0.125 in | 3.18 mm | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Through Hole | Push-Pull | 20 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | |||
Mill-Max Manufacturing Corp. | 1 | 0.125 in | 3.18 mm | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Through Hole | Push-Pull | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | 33 | |||
Mill-Max Manufacturing Corp. | 1 | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Surface Mount | Push-Pull | 8 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | 5.6 mm | 0.22 in | |||
 Mill-Max Manufacturing Corp. | 1 | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Surface Mount | Push-Pull | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | 5.6 mm | 0.22 in | ||||
Mill-Max Manufacturing Corp. | 1 | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Surface Mount | Push-Pull | 38 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | 5.6 mm | 0.22 in | |||
Mill-Max Manufacturing Corp. | 1 | 0.125 in | 3.18 mm | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Through Hole | Push-Pull | 22 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper | |||
Mill-Max Manufacturing Corp. | 1 | 0.125 in | 3.18 mm | Tin-Lead | 0.1 " | 2.54 mm | All | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 100 V | 150 VDC | UL94 V-0 | Gold | Through Hole | Push-Pull | 11 | -55 C | 125 °C | 200 µin | 5.08 µm | Black | 3 A | 0.76 Ám | 30 Áin | Receptacle | Solder | Circular | Female Socket | Beryllium Copper |
