174-E25 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 25POS R/A SLDR
| Part | Contact Material | Color | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Connector Type | Current Rating (Amps) | Features | Backset Spacing | Backset Spacing | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Material Flammability Rating | Contact Finish | Connector Style | Contact Type | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Number of Positions | Flange Feature | Termination | Number of Rows [custom] | Mounting Type | Contact Finish Thickness | Shell Material, Finish | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | White | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | Plug Male Pins | 5 A | Mounting Brackets | 9.4 mm | 0.37 in | B DB | 3 | UL94 V-0 | Gold | D-Sub | Signal | Steel | Yellow Chromate Plated | 25 | Mating Side Standard Screws (4-40) | Solder | 2 | Panel Mount Right Angle Through Hole | Flash | ||
 NorComp Inc. | Brass | White | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | Receptacle Female Sockets | 5 A | Mounting Brackets | 9.4 mm | 0.37 in | B DB | 3 | UL94 V-0 | Gold | D-Sub | Signal | 25 | 4-40 Mating Side Female Screwlock | Solder | 2 | Panel Mount Right Angle Through Hole | Flash | Nickel Plated Steel | |||
 NorComp Inc. | White | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | Plug Male Pins | 5 A | Mounting Brackets | 9.4 mm | 0.37 in | B DB | 3 | UL94 V-0 | Gold | D-Sub | Signal | Steel | Yellow Chromate Plated | 25 | 4-40 Mating Side Female Screwlock | Solder | 2 | Panel Mount Right Angle Through Hole | Flash | |||
 NorComp Inc. | Brass | White | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | Receptacle Female Sockets | 5 A | 9.4 mm | 0.37 in | B DB | 3 | UL94 V-0 | Gold | D-Sub | Signal | 25 | Housing/Shell (Unthreaded) | Solder | 2 | Panel Mount Right Angle Through Hole | Flash | Nickel Plated Steel | ||||
 NorComp Inc. | Brass | White | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | Plug Male Pins | 5 A | Board Lock Grounding Indents Mounting Brackets | 9.4 mm | 0.37 in | B DB | 3 | UL94 V-0 | Gold | D-Sub | Signal | 25 | Housing/Shell | Solder | 2 | Panel Mount Right Angle Through Hole | Flash | Nickel Plated Steel | 4-40 | ||
 NorComp Inc. | Brass | White | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | Receptacle Female Sockets | 5 A | Mounting Brackets | 9.4 mm | 0.37 in | B DB | 3 | UL94 V-0 | Gold | D-Sub | Signal | Steel | Yellow Chromate Plated | 25 | Mating Side Standard Screws (4-40) | Solder | 2 | Panel Mount Right Angle Through Hole | Flash |
