8532/R Series
Manufacturer: Delevan
Beta
⌘K
POWER INDUCTORS - SMD 1.5UH 10% .011OHM HI CURRENT CHOKE SMT
| Part | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Material - Core | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Inductance Frequency - Test | DC Resistance (DCR) [Max] | Inductance | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Shielding | Tolerance | Mounting Type | Current - Saturation (Isat) | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delevan | 0.88 " | 22.35 mm | 0.33 " | 8.38 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 11 mOhm | 1.5 µH | -55 C | 125 °C | 2-SMD | Unshielded | 10 % | Surface Mount | 5.2 A | 5.67 A |
 Delevan | 0.88 " | 22.35 mm | 0.33 " | 8.38 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 84 mOhm | 39 µH | -55 C | 125 °C | 2-SMD | Unshielded | 15 % | Surface Mount | 1 A | 2.05 A |
Delevan | 0.88 " | 22.35 mm | 0.33 " | 8.38 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 2.3 Ohm | 1 mH | -55 C | 125 °C | 2-SMD | Unshielded | 5 % | Surface Mount | 200 mA | 390 mA |
Delevan | 0.88 " | 22.35 mm | 0.33 " | 8.38 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 650 mOhm | 330 µH | -55 C | 125 °C | 2-SMD | Unshielded | 15 % | Surface Mount | 350 mA | 0.74 A |
Delevan | 0.86 " | 21.84 mm | 0.32 " | 8.12 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 152 mOhm | 82 µH | -55 C | 125 °C | Nonstandard | Unshielded | 15 % | Surface Mount | 710 mA | 1.53 A |
Delevan | 0.86 " | 21.84 mm | 0.32 " | 8.12 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 40 Ohm | 18 mH | -55 C | 125 °C | Nonstandard | Unshielded | 15 % | Surface Mount | 50 mA | 0.09 A |
Delevan | 0.86 " | 21.84 mm | 0.32 " | 8.12 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 13 mOhm | 2.2 µH | -55 C | 125 °C | Nonstandard | Unshielded | 15 % | Surface Mount | 4.3 A | 5.22 A |
Delevan | 0.88 " | 22.35 mm | 0.33 " | 8.38 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 3 Ohm | 1.5 mH | -55 C | 125 °C | 2-SMD | Unshielded | 10 % | Surface Mount | 160 mA | 0.34 A |
Delevan | 0.88 " | 22.35 mm | 0.33 " | 8.38 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 6.56 Ohm | 3300 µH | -55 C | 125 °C | 2-SMD | Unshielded | 3 % | Surface Mount | 110 mA | 0.23 A |
Delevan | 0.88 " | 22.35 mm | 0.33 " | 8.38 mm | Ferrite | 0.286 in | 7.26 mm | 1 kHz | 23.4 Ohm | 10 mH | -55 C | 125 °C | 2-SMD | Unshielded | 15 % | Surface Mount | 60 mA | 120 mA |
