SG-8018CB PR Series
Manufacturer: EPSON
Beta
⌘K
STANDARD CLOCK OSCILLATORS SG-8018CB 98.7650M-TJHSA0: MHZ OSC 1.8V~3.3V +/-50PPM -40~105C ST 1K TR
| Part | Current - Supply (Disable) (Max) | Function | Mounting Type | Frequency Stability | Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Output | Base Resonator [custom] | Frequency | Current - Supply (Max) [Max] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) | Current - Supply (Disable) (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1.1 µA | Standby (Power Down) | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 98.765 MHz | 8.1 mA | 0.051 in | 1.3 mm | ||
Enable/Disable | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 26.562 MHz | 8.1 mA | 0.051 in | 1.3 mm | 3.5 mA | ||
Enable/Disable | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 54.875 MHz | 8.1 mA | 0.051 in | 1.3 mm | 3.5 mA | ||
Standby (Power Down) | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 19.968 MHz | 3.5 mA | 0.051 in | 1.3 mm | |||
Enable/Disable | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 54.36 MHz | 8.1 mA | 0.051 in | 1.3 mm | 3.5 mA | ||
Enable/Disable | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 24.9231 MHz | 8.1 mA | 0.051 in | 1.3 mm | |||
Enable/Disable | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 37.6 MHz | 8.1 mA | 0.051 in | 1.3 mm | 3.5 mA | ||
Standby (Power Down) | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 66.155 MHz | 8.1 mA | 0.051 in | 1.3 mm | |||
Enable/Disable | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 1.96608 MHz | 3.5 mA | 0.051 in | 1.3 mm | 3.5 mA | ||
Enable/Disable | Surface Mount | 50 ppm | XO (Standard) | 1.62 V | 3.63 V | 3.2 mm | 0.126 in | 5 mm | 0.197 in | -40 C | 105 ░C | 4-SMD No Lead | CMOS | Crystal | 9.96125 MHz | 3.5 mA | 0.051 in | 1.3 mm |
