VLDB1232 Series

Catalog

LED BLUE 2SMD BOTTOM ENT

Part	Color	Current - Test	Supplier Device Package	Lens Size [diameter]	Viewing Angle	Voltage - Forward (Vf) (Typ)	Lens Style	Millicandela Rating	Mounting Type	Package / Case	Height (Max) [z]	Wavelength - Peak	Wavelength - Dominant	Size / Dimension [y]	Size / Dimension [x]	Height (Max) [Max] [z]	Height (Max) [z]
Vishay Semiconductor Opto Division VLDB1232R-08	Blue	20 mA	2-SMD	1.8 mm Dia	18 °	3 V	Round with Domed Top	3500 mcd	Surface Mount Bottom Entry	2-SMD Z-Bend	2.97 mm	460 nm	465 nm	2.3 mm	2.3 mm
Vishay Semiconductor Opto Division VLDB1232RG-08	Blue	20 mA	2-SMD	1.8 mm Dia	18 °	3 V	Round with Domed Top	3500 mcd	Surface Mount	2-SMD Gull Wing		460 nm	465 nm	2.3 mm	2.3 mm	3.12 mm
Vishay Semiconductor Opto Division VLDB1232G-08	Blue	20 mA	2-SMD	1.8 mm Dia	18 °	3 V	Round with Domed Top	3500 mcd	Surface Mount	2-SMD Gull Wing		460 nm	465 nm	2.3 mm	2.3 mm		3.02 mm
