345-041 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 41POS 0.100
...
| Part | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch [x] | Pitch [x] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Material - Insulation | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Read Out | Termination Rows | Number of Rows | Number of Positions | Contact Material | Termination | Gender | Contact Type | Color | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole Right Angle | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Solder | Female | Cantilever | Green | |
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | M3 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Solder | Female | Cantilever | Green | |||
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 3.96 mm | Top Mount Opening Unthreaded | 0.156 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Wire Wrap | Female | Cantilever | Green | |
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Solder | Female | Cantilever | Green | Card Guides | ||
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Solder | Female | Cantilever | Green | Card Guides | ||
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Solder Eyelet(s) | Female | Cantilever | Green | Card Guides | ||
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 3.96 mm | Top Mount Opening Unthreaded | 0.156 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Wire Wrap | Female | Cantilever | Green | |
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Solder | Female | Cantilever | Green | Card Guides | ||
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole Right Angle | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | M3 Threaded Insert Top Mount Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Wire Wrap | Female | Cantilever | Green | |||
 EDAC Inc. | Non Specified - Single Edge | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Through Hole | 10 Áin | 0.25 Ám | Gold | Polyester Thermoplastic | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 1 | 1 | 41 | Copper Alloy | Solder | Female | Cantilever | Green |
