D-HR Series
Manufacturer: Sensata-Crydom
Beta
⌘K
RELAY REED 5KV 5V SPST-NO
| Part | Release Time | Operate Time | Contact Form | Coil Type | Mounting Type | Switching Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Contact Rating (Current) | Must Release Voltage | Coil Current | Coil Voltage | Must Operate Voltage | Contact Material | Termination Style | Switching Voltage [Max] | Coil Resistance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | 2 ms | 3 ms | SPST-NO (1 Form A) | Non Latching | Through Hole | 3500 VDC 3500 VAC | -20 ░C | 70 °C | 2 A | 0.5 VDC | 179 mA | 5 VDC | 3.7 VDC | Tungsten (W) | PC Pin Wire Leads | ||
Sensata-Crydom | 3 ms | 2 ms | SPST-NC (1 Form B) | Non Latching | Through Hole | -20 ░C | 70 °C | 2 A | 4 VDC | 25.9 mA | 24 VDC | 20 VDC | Tungsten (W) | PC Pin | 5000 VDC 5000 VAC | ||
 Sensata-Crydom | 2 ms | 3 ms | SPST-NO (1 Form A) | Non Latching | Through Hole | -20 ░C | 70 °C | 3 A | 0.5 VDC | 179 mA | 5 VDC | 3.7 VDC | Rhodium (Rh) | PC Pin Wire Leads | 1000 VAC 1000 VDC | ||
 Sensata-Crydom | 2 ms | 3 ms | SPST-NO (1 Form A) | Non Latching | Through Hole | -20 ░C | 70 °C | 3 A | 0.5 VDC | 179 mA | 5 VDC | 3.7 VDC | Rhodium (Rh) | PC Pin Wire Leads | 1000 VAC 1000 VDC | 28 Ohms | |
 Sensata-Crydom | 3 ms | 2 ms | SPST-NC (1 Form B) | Non Latching | Through Hole | 7000 VAC 7000 VDC | -20 ░C | 70 °C | 2 A | 0.5 VDC | 132 mA | 5 VDC | 3.7 VDC | Tungsten (W) | PC Pin | 38 Ohms | |
Sensata-Crydom | 3 ms | 2 ms | SPST-NC (1 Form B) | Non Latching | Through Hole | -20 ░C | 70 °C | 3 A | 0.5 VDC | 132 mA | 5 VDC | 3.7 VDC | Rhodium (Rh) | PC Pin Wire Leads | 1000 VAC 1000 VDC | ||
 Sensata-Crydom | 2 ms | 3 ms | SPST-NO (1 Form A) | Non Latching | Through Hole | -20 ░C | 70 °C | 2 A | 1.25 VDC | 80 mA | 12 VDC | 9 VDC | Tungsten (W) | PC Pin Wire Leads | 5000 VDC 5000 VAC | ||
Sensata-Crydom | 2 ms | 3 ms | SPST-NO (1 Form A) | Non Latching | Through Hole | 7000 VAC 7000 VDC | -20 ░C | 70 °C | 2 A | 1.25 VDC | 80 mA | 12 VDC | 9 VDC | Tungsten (W) | PC Pin Wire Leads | ||
Sensata-Crydom | 3 ms | 2 ms | SPST-NC (1 Form B) | Non Latching | Through Hole | -20 ░C | 70 °C | 3 A | 1.25 VDC | 50 mA | 12 VDC | 9 VDC | Rhodium (Rh) | PC Pin Wire Leads | 1000 VAC 1000 VDC | ||
Sensata-Crydom | 2 ms | 3 ms | SPST-NO (1 Form A) | Non Latching | Through Hole | 7000 VAC 7000 VDC | -20 ░C | 70 °C | 2 A | 4 VDC | 30.8 mA | 24 VDC | 20 VDC | Tungsten (W) | PC Pin Wire Leads |
