PGSB Series

Catalog

GROMMET, OPEN, 25 MM, NYLON 6.6 (POLYAMIDE 6.6), 30 MM, 13.1 MM

Part	Material Flammability Rating	Features	Bushing, Grommet Type	Diameter - Inside [diameter]	Diameter - Inside [diameter]	For Use With/Related Products	Panel Thickness [Max]	Panel Thickness [Min]	Panel Cutout Dimensions [diameter]	Panel Cutout Dimensions [diameter]	Color	Material	Panel Thickness [Min] [x]	Panel Thickness [Min] [x]	Panel Thickness [Max] [x]	Panel Thickness [Max] [x]	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Max]	Diameter - Inside	Diameter - Inside	Panel Thickness	Panel Thickness
Essentra Components PGSB-2530	UL94 V-2	Snap-Mount	Bushing	24.99 mm	0.984 in	Cable Wires	0.122 in 3.1 mm	0.039 in 0.99 mm	30 mm	1.181 in	Black	Polyamide (PA66) Nylon 6/6
Essentra Components PGSB-1316	UL94 V-2	Snap-Mount	Bushing	12.8 mm	0.504 in	Cable Wires			16 mm	0.63 "	Black	Polyamide (PA66) Nylon 6/6	0.055 "	1.4 mm	0.139 "	3.53 mm
Essentra Components PGSB-1519A	UL94 V-2	Snap-Mount	Bushing Split	14.48 mm	0.57 in	Cable Wires	0.13 in	0.047 in	19 mm	0.748 in	Black	Polyamide (PA66) Nylon 6/6					3.3 mm	1.19 mm
Essentra Components PGSB-17	UL94 V-2	Snap-Mount	Bushing	6.35 mm	0.25 in	Cable Wires	0.125 "	0.031 "	15.88 mm	0.625 in	Black	Polyamide (PA66) Nylon 6/6						0.79 mm	3.18 mm
Essentra Components PGSB-1316A	UL94 V-2	Snap-Mount	Bushing Split			Cable Wires	0.138 in	0.047 in	16 mm	0.63 "	Black	Polyamide (PA66) Nylon 6/6						1.19 mm	3.51 mm	0.41 in	10.41 mm
Essentra Components PGSB-9A	UL94 V-2	Snap-Mount	Bushing Split	20.4 mm	0.803 in	Cable Wires	0.118 in	0.031 "	24.99 mm	0.984 in	Black	Polyamide (PA66) Nylon 6/6										0.79 mm 3 mm
Essentra Components PGSB-30	UL94 V-2	Snap-Mount	Bushing	19.05 mm	0.75 in	Cable Wires			22.22 mm	0.875 in	Black	Polyamide (PA66) Nylon 6/6										1.57 mm	0.062 "
Essentra Components PGSB-37	UL94 V-2	Snap-Mount	Bushing	26.97 mm	1.062 in	Cable Wires	0.125 "	0.031 "	38.1 mm	1.5 in	Black	Polyamide (PA66) Nylon 6/6						0.79 mm	3.18 mm
Essentra Components PGSB-20	UL94 V-2	Snap-Mount	Bushing	12.7 mm	0.5 in	Cable Wires	0.125 "	0.031 "	17.45 mm	0.687 in	Black	Polyamide (PA66) Nylon 6/6						0.79 mm	3.18 mm
Essentra Components PGSB-31	UL94 V-2	Snap-Mount	Bushing	19.46 mm	0.766 in	Cable Wires	0.125 "	0.031 "	25.4 mm	1 in	Black	Polyamide (PA66) Nylon 6/6						0.79 mm	3.18 mm
