DE1B3KX Series

Catalog

CAP CER

Part	Lead Style	Capacitance	Ratings [custom]	Ratings [custom]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lead Spacing	Lead Spacing	Applications	Temperature Coefficient	Features	Voltage - Rated	Mounting Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Tolerance	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Murata Electronics DE1B3KX221KJ4BP01F
Murata Electronics DE1B3KX681KN4AP01F	Straight	680 pF	X1	Y1	11 mm	0.433 in	0.394 in	10 mm	Safety	B	Flame Retardant	250 VAC	Through Hole	0.315 in	8 mm	125 °C	-40 C	10 %	Disc Radial
Murata Electronics DE1B3KX221KA4BP01F	Straight	220 pF	X1	Y1	11 mm	0.433 in	0.394 in	10 mm	Safety	B	Flame Retardant	250 VAC	Through Hole	0.315 in	8 mm	125 °C	-40 C	10 %	Disc Radial
Murata Electronics DE1B3KX471KB4BP01F	Straight	470 pF	X1	Y1			0.394 in	10 mm	Safety	B	Flame Retardant	250 VAC	Through Hole	0.276 in	7 mm	125 °C	-40 C	10 %	Disc Radial	10 mm	0.394 in
Murata Electronics DE1B3KX101KB4BN01F	Straight	100 pF	X1	Y1			0.394 in	10 mm	Safety	B	Flame Retardant	250 VAC	Through Hole	0.276 in	7 mm	125 °C	-40 C	10 %	Disc Radial	10 mm	0.394 in
Murata Electronics DE1B3KX151KA4BN01F	Straight	150 pF	X1	Y1			0.394 in	10 mm	Safety	B	Flame Retardant	250 VAC	Through Hole	0.276 in	7 mm	125 °C	-40 C	10 %	Disc Radial	10 mm	0.394 in
Murata Electronics DE1B3KX101KN4AN01F	Straight	100 pF	X1	Y1			0.394 in	10 mm	Safety	B	Flame Retardant	250 VAC	Through Hole	0.276 in	7 mm	125 °C	-40 C	10 %	Disc Radial	10 mm	0.394 in
Murata Electronics DE1B3KX331KJ4BN01F
Murata Electronics DE1B3KX331KJ4BP01F
Murata Electronics DE1B3KX331KB4BP01F	Straight	330 pF	X1	Y1			0.394 in	10 mm	Safety	B	Flame Retardant	250 VAC	Through Hole	0.276 in	7 mm	125 °C	-40 C	10 %	Disc Radial	10 mm	0.394 in
