EET-UQ Series
Manufacturer: Panasonic Industrial Automation Sales
Catalog
CAP ALUM 390UF 20% 200V SNAP TH
...
| Part | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Package / Case | Lifetime @ Temp. | Voltage - Rated | Mounting Type | ESR (Equivalent Series Resistance) | Capacitance | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Tolerance | Size / Dimension [diameter] | Size / Dimension [diameter] | Polarization | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Lead Spacing | Lead Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | 0.984 " | 25 mm | Radial Can - Snap-In | 2000 Hrs | 200 V | Through Hole | 510 mOhm | 390 µF | 1.68 A | 2.352 A | 20 % | 22 mm | 0.866 in | Polar | General Purpose | 85 °C | -40 °C | ||
 Panasonic Industrial Automation Sales | 1.575 in | 40 mm | Radial Can - Snap-In | 2000 Hrs | 250 V | Through Hole | 133 mOhm | 1.5 mF | 4.04 A | 5.656 A | 20 % | 35 mm | 1.378 in | Polar | General Purpose | 85 °C | -40 °C | 0.394 in | 10 mm |
 Panasonic Industrial Automation Sales | 1.378 in | 35 mm | Radial Can - Snap-In | 2000 Hrs | 400 V | Through Hole | 737 mOhm | 270 µF | 1.67 A | 2.338 A | 20 % | 25 mm | 0.984 " | Polar | General Purpose | 85 °C | -25 °C | ||
Panasonic Industrial Automation Sales | 0.984 " | 25 mm | Radial Can - Snap-In | 2000 Hrs | 16 V | Through Hole | 46 mOhm | 18000 µF | 5.57 A | 6.406 A | 20 % | 25 mm | 0.984 " | Polar | General Purpose | 85 °C | -40 °C | 0.394 in | 10 mm |
Panasonic Industrial Automation Sales | 1.772 in | 45 mm | Radial Can - Snap-In | 2000 Hrs | 350 V | Through Hole | 243 mOhm | 820 µF | 3.25 A | 4.55 A | 20 % | 35 mm | 1.378 in | Polar | General Purpose | 85 °C | -25 °C | ||
Panasonic Industrial Automation Sales | Radial Can - Snap-In | 2000 Hrs | 450 V | Through Hole | 737 mOhm | 270 µF | 1.78 A | 2.492 A | 20 % | 22 mm | 0.866 in | Polar | General Purpose | 85 °C | -25 °C | ||||
Panasonic Industrial Automation Sales | 1.378 in | 35 mm | Radial Can - Snap-In | 2000 Hrs | 250 V | Through Hole | 166 mOhm | 1.2 mF | 3.53 A | 4.942 A | 20 % | 35 mm | 1.378 in | Polar | General Purpose | 85 °C | -40 °C | 0.394 in | 10 mm |
 Panasonic Industrial Automation Sales | 1.575 in | 40 mm | Radial Can - Snap-In | 2000 Hrs | 350 V | Through Hole | 355 mOhm | 560 µF | 2.6 A | 3.64 A | 20 % | 30 mm | 1.181 inches | Polar | General Purpose | 85 °C | -25 °C | 0.394 in | 10 mm |
Panasonic Industrial Automation Sales | 1.378 in | 35 mm | Radial Can - Snap-In | 2000 Hrs | 450 V | Through Hole | 510 mOhm | 390 µF | 3.136 A | 20 % | 35 mm | 1.378 in | Polar | General Purpose | 85 °C | -25 °C | |||
Panasonic Industrial Automation Sales | 1.378 in | 35 mm | Radial Can - Snap-In | 2000 Hrs | 350 V | Through Hole | 904 mOhm | 220 µF | 1.44 A | 2.016 A | 20 % | 22 mm | 0.866 in | Polar | General Purpose | 85 °C | -25 °C |
