307-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 44 CONTACTS, THROUGH HOLE MOUNT, RIGHT ANGLE
| Part | Termination Rows | Material - Insulation | Color | Contact Type | Termination | Number of Positions/Bay/Row | Contact Material | Number of Positions | Card Type | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Mounting Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Read Out | Termination Rows [custom] | Number of Positions/Bay/Row [custom] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | Semi Bellows | Solder | 44 | Copper Alloy | 88 | Non Specified - Dual Edge | Tin | -40 C | 105 ░C | Female | Right Angle Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | ||||||
 EDAC Inc. | Polyester Thermoplastic | Green | Semi Bellows | Solder Wire Wrap | Copper Alloy | 44 | Non Specified - Dual Edge | Gold | -40 C | 105 ░C | Female | Right Angle Through Hole | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 2 | 21 | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | Semi Bellows | Solder Eyelet(s) | 44 | Copper Alloy | 44 | Non Specified - Single Edge | Tin | -40 C | 105 ░C | Female | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | ||||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | Semi Bellows | Wire Wrap | 44 | Copper Alloy | 44 | Non Specified - Single Edge | Tin | -40 C | 105 ░C | Female | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | Card Guides | |||||||
 EDAC Inc. | Polyester Thermoplastic | Green | Semi Bellows | Solder | 22 | Copper Alloy | 44 | Non Specified - Dual Edge | Tin | -40 C | 105 ░C | Female | Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Green | Semi Bellows | Solder Eyelet(s) | 22 | Copper Alloy | 44 | Non Specified - Dual Edge | Tin | -40 C | 105 ░C | Female | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 2 | ||||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | Semi Bellows | Solder | 44 | Copper Alloy | 44 | Non Specified - Single Edge | Gold | -40 C | 105 ░C | Female | Right Angle Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 0.25 Ám | 10 Áin | 1 | Card Guides | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | Semi Bellows | Solder | 44 | Copper Alloy | 88 | Non Specified - Dual Edge | Gold | -40 C | 105 ░C | Female | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 0.25 Ám | 10 Áin | Card Guides | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | Semi Bellows | Solder | 44 | Copper Alloy | 88 | Non Specified - Dual Edge | Tin | -40 C | 105 ░C | Female | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | |||||||||
 EDAC Inc. | Polyester Thermoplastic | Green | Semi Bellows | Solder | 22 | Copper Alloy | 44 | Non Specified - Dual Edge | Gold | -40 C | 105 ░C | Female | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Dual | 2 | 0.25 Ám | 10 Áin | Card Guides |
