257 PRM-SI Series
Manufacturer: Vishay Dale
Beta
⌘K
ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 1000UF 200V 25X45MM
| Part | Applications | Capacitance | Operating Temperature (Min) | Operating Temperature (Max) | ESR (Equivalent Series Resistance) | Size / Dimension Diameter | Lead Spacing | Ripple Current | Polarization | Height - Seated (Max) | Voltage - Rated | Lifetime | Impedance | Package / Case | Tolerance | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay Dale | General Purpose | 1000 µF | -40 °C | 85 °C | 160 mOhm | 0.984 in | 0.394 in | 3.11 A 4.354 A | Polar | 1.85 in | 200 VDC | 5000 Hrs | 110 mOhm | Can - Snap-In Radial | 20 % | Through Hole |
