CL-165 Series
Manufacturer: Citizen Finedevice Co Ltd
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
LED GREEN/RED SMD
| Part | Lens Length | Lens Width | Height (Max) | Color | Wavelength - Dominant Color | Wavelength - Dominant (Green) | Wavelength - Dominant (Red) | Size / Dimension Width | Size / Dimension Length | Mounting Type | Current - Test (Green) | Current - Test Colors | Current - Test (Red) | Package / Case | Configuration | Lens Style | Millicandela Rating Colors | Millicandela Rating (Green) | Millicandela Rating (Red) | Voltage - Forward (Vf) (Typ) Color | Voltage - Forward (Vf) (Typ) (Red) | Voltage - Forward (Vf) (Typ) (Green) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Citizen Finedevice Co Ltd | 1.5 mm | 1.2 mm | 0.7 mm | Green Red | Green Red | 575 nm | 640 nm | 1.2 mm | 1.5 mm | Surface Mount | 20 mA | Green Red | 20 mA | 2-SMD No Lead | Independent | Flat Top Rectangle | Green Red | 18 mcd | 23 mcd | Green Red | 1.8 V | 2.2 V |
