U-Channel Power Supply 12V 300 Watt
U-Channel Power Supply 12V 300 Watt
| Part | Number of Outputs | Power (Watts) | Voltage - Input [Max] | Voltage - Input [Min] | Current - Output 1 | Voltage - Output 1 | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Standard Number | Features | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Efficiency | Applications | Type | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TT Electronics/BI | 1 | 200 Watts 300 W | 264 VAC | 90 VAC | 12.5 A | 24 V | CE cURus TUV | 70 °C | 0 °C | 60601-1 60950-1 | DC Input Capable PFC Remote Sense Standby Output Universal Input | 152.4 mm | 76.2 mm | 3 " | 6 in | 35.1 mm | 1.38 " | 92 % | ITE (Commercial) Medical | Open Frame | Chassis Mount |
TT Electronics/BI | 1 | 200 Watts 300 W | 264 VAC | 90 VAC | 20 A | 15 V | CE cURus TUV | 70 °C | 0 °C | 60601-1 60950-1 | DC Input Capable PFC Remote Sense Standby Output Universal Input | 152.4 mm | 76.2 mm | 3 " | 6 in | 35.1 mm | 1.38 " | 92 % | ITE (Commercial) Medical | Open Frame | Chassis Mount |
 TT Electronics/BI | 1 | 200 Watts 300 W | 264 VAC | 90 VAC | 25 A | 12 V | CE cURus TUV | 70 °C | 0 °C | 60601-1 60950-1 | DC Input Capable PFC Remote Sense Standby Output Universal Input | 152.4 mm | 76.2 mm | 3 " | 6 in | 35.1 mm | 1.38 " | 91 % | ITE (Commercial) Medical | Open Frame | Chassis Mount |
