NPO/X7R Series
Manufacturer: YAGEO
Beta
⌘K
SMD MULTILAYER CERAMIC CAPACITOR, CC SERIES, 4700 PF, 2 KV, 1812 [4532 METRIC], ± 5%, X7R
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Applications | Thickness (Max) | Thickness (Max) [Max] [z] | Voltage - Rated | Voltage - Rated | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Tolerance | Package / Case | Capacitance | Mounting Type | Temperature Coefficient | Thickness (Max) [Max] | Thickness (Max) [Max] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 YAGEO | -55 C | 125 °C | General Purpose | 1.5 mm | 0.059 in | 2000 V | 2 kV | 0.177 in | 4.5 mm | 3.2 mm | 0.126 in | 10 % | 1812 (4532 Metric) | 0.0047 µF | MLCC Surface Mount | X7R | |||
 YAGEO | -55 C | 125 °C | General Purpose | 2000 V | 2 kV | 0.177 in | 4.5 mm | 2 mm | 0.079 in | 10 % | 1808 (4520 Metric) | 470 pF | MLCC Surface Mount | X7R | 1.8 mm | 0.071 in | High Voltage | ||
 YAGEO | -55 C | 125 °C | General Purpose | 630 V | 0.126 " | 3.2 mm | 1.6 mm | 0.063 " | 5 % | 1206 (3216 Metric) | 6800 pF | MLCC Surface Mount | C0G NP0 | 1.45 mm | 0.057 " | ||||
 YAGEO | -55 C | 125 °C | General Purpose | 1000 V | 1 kV | 0.126 " | 3.2 mm | 1.6 mm | 0.063 " | 5 % | 1206 (3216 Metric) | 68 pF | MLCC Surface Mount | C0G NP0 | 1.45 mm | 0.057 " | High Voltage | ||
YAGEO | -55 C | 125 °C | General Purpose | 1000 V | 1 kV | 0.126 " | 3.2 mm | 1.6 mm | 0.063 " | 5 % | 1206 (3216 Metric) | 180 pF | MLCC Surface Mount | C0G NP0 | 1.45 mm | 0.057 " | High Voltage | ||
YAGEO | -55 C | 125 °C | General Purpose | 3000 V | 3 kV | 0.177 in | 4.5 mm | 2 mm | 0.079 in | 10 % | 1808 (4520 Metric) | 560 pF | MLCC Surface Mount | X7R | 1.8 mm | 0.071 in | High Voltage | ||
 YAGEO | -55 C | 125 °C | General Purpose | 3000 V | 3 kV | 0.177 in | 4.5 mm | 3.2 mm | 0.126 in | 5 % | 1812 (4532 Metric) | 56 pF | MLCC Surface Mount | C0G NP0 | 1.45 mm | 0.057 " | High Voltage | ||
 YAGEO | -55 C | 125 °C | General Purpose | 1000 V | 1 kV | 0.126 " | 3.2 mm | 1.6 mm | 0.063 " | 5 % | 1206 (3216 Metric) | 680 pF | MLCC Surface Mount | C0G NP0 | 1.45 mm | 0.057 " | High Voltage | ||
YAGEO | -55 C | 125 °C | General Purpose | 2000 V | 2 kV | 0.126 " | 3.2 mm | 1.6 mm | 0.063 " | 5 % | 1206 (3216 Metric) | 22 pF | MLCC Surface Mount | C0G NP0 | 1.45 mm | 0.057 " | High Voltage | ||
YAGEO | -55 C | 125 °C | General Purpose | 1.5 mm | 0.059 in | 2000 V | 2 kV | 0.177 in | 4.5 mm | 3.2 mm | 0.126 in | 10 % | 1812 (4532 Metric) | 0.0033 µF | MLCC Surface Mount | X7R | High Voltage |
