CEB100W Series

Manufacturer: Cincon Electronics Co. LTD

Catalog

ISOLATED DC/DC CONVERTERS 100W,

Part	Supplier Device Package	Standard Number	Applications	Control Features	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Isolation	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Number of Outputs	Current - Output (Max) [Max]	Efficiency	Power (Watts)	Package / Case	Features	Approval Agency	Type	Voltage - Output 1	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Input (Max) [Max]
Cincon Electronics Co. LTD CEB100W-24S05N-F	Eighth Brick	62368-1	ITE (Commercial)	Active Low Enable	9 V	105 C	-40 °C	3000 V	0.5 in	2.45 in 62.2 mm	1.45 in 36.8 mm	1	20 A	92 %	100 W	Eighth Brick	Adjustable Output Baseplate Remote On/Off	CB CE cURus UKCA	Isolated Module	5 V	Through Hole
Cincon Electronics Co. LTD CEB100W-24S12N-F	Eighth Brick	62368-1	ITE (Commercial)	Active Low Enable	9 V	105 C	-40 °C	3000 V	0.5 in	2.45 in 62.2 mm	1.45 in 36.8 mm	1	8.3 A	92.5 %	100 W	Eighth Brick	Adjustable Output Baseplate Remote On/Off	CB CE cURus UKCA	Isolated Module	12 V	Through Hole
Cincon Electronics Co. LTD CEB100W-48S05	Eighth Brick	62368-1	ITE (Commercial)	Active High Enable	16.5 V	105 C	-40 °C	3000 V	0.5 in	2.45 in	1.05 in	1	20 A	92.5 %	100 W	Eighth Brick	Adjustable Output Remote On/Off	CB CE cURus UKCA	Isolated Module	5 V	Through Hole	62.2 mm	26.6 mm	12.7 mm	74 V
Cincon Electronics Co. LTD CEB100W-24S54	Eighth Brick	62368-1	ITE (Commercial)	Active High Enable	9 V	105 C	-40 °C	3000 V	0.5 in	2.45 in	1.05 in	1	1.85 A	91 %	100 W	Eighth Brick	Adjustable Output Remote On/Off	CB CE cURus UKCA	Isolated Module	54 V	Through Hole	62.2 mm	26.6 mm	12.7 mm
Cincon Electronics Co. LTD CEB100W-48S05N-F	Eighth Brick	62368-1	ITE (Commercial)	Active Low Enable	16.5 V	105 C	-40 °C	3000 V	0.5 in	2.45 in 62.2 mm	1.45 in 36.8 mm	1	20 A	92.5 %	100 W	Eighth Brick	Adjustable Output Baseplate Remote On/Off	CB CE cURus UKCA	Isolated Module	5 V	Through Hole				74 V
Cincon Electronics Co. LTD CEB100W-48S54-F	Eighth Brick	62368-1	ITE (Commercial)	Active High Enable	16.5 V	105 C	-40 °C	3000 V	0.5 in	2.45 in 62.2 mm	1.45 in 36.8 mm	1	1.85 A	91.5 %	100 W	Eighth Brick	Adjustable Output Baseplate Remote On/Off	CB CE cURus UKCA	Isolated Module	54 V	Through Hole				74 V
Cincon Electronics Co. LTD CEB100W-48S24N	Eighth Brick	62368-1	ITE (Commercial)	Active Low Enable	16.5 V	105 C	-40 °C	3000 V	0.5 in	2.45 in	1.05 in	1	4.2 A	90.5 %	100 W	Eighth Brick	Adjustable Output Remote On/Off	CB CE cURus UKCA	Isolated Module	24 V	Through Hole	62.2 mm	26.6 mm	12.7 mm	74 V
Cincon Electronics Co. LTD CEB100W-48S24-F	Eighth Brick	62368-1	ITE (Commercial)	Active High Enable	16.5 V	105 C	-40 °C	3000 V	0.5 in	2.45 in 62.2 mm	1.45 in 36.8 mm	1	4.2 A	91 %	100 W	Eighth Brick	Adjustable Output Baseplate Remote On/Off	CB CE cURus UKCA	Isolated Module	24 V	Through Hole				74 V
