RP131 Series
Manufacturer: Nisshinbo Micro Devices Inc.
Beta
⌘K
IC REG LINEAR 1.8V 1A DFN1616-6B
| Part | Package / Case | Protection Features | PSRR | Output Configuration | Current - Quiescent (Iq) | Voltage - Input (Max) [Max] | Control Features | Supplier Device Package | Number of Regulators | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output | Mounting Type | Voltage - Output (Min/Fixed) | Voltage Dropout (Max) | Voltage Dropout (Max) [Max] | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nisshinbo Micro Devices Inc. | 6-XFDFN Exposed Pad | Over Current Over Temperature | 70 db | Positive | 90 çA | 6.5 V | Enable | DFN1616-6B | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 1.8 V | 1.1 V | ||
Nisshinbo Micro Devices Inc. | 6-XFDFN Exposed Pad | Over Current Over Temperature | 70 db | Positive | 90 çA | 6.5 V | Enable | DFN1616-6B | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 1.2 V | 1.38 V | ||
 Nisshinbo Micro Devices Inc. | 4 Leads + 2 Fins 6-SOIC Variation | Over Current Over Temperature | 60 dB | Positive | 90 çA | 6.5 V | Enable | 6-HSOP-J | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 3.4 V | 0.65 V | 0.154 in 3.9 mm | |
 Nisshinbo Micro Devices Inc. | 6-UFDFN Exposed Pad | Over Current Over Temperature | 60 dB | Positive | 90 çA | 6.5 V | Enable | DFN(PL)1820-6 | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 4 V | 0.65 V | ||
Nisshinbo Micro Devices Inc. | 4 Leads + 2 Fins 6-SOIC Variation | Over Current Over Temperature | 70 db | Positive | 90 çA | 6.5 V | Enable | 6-HSOP-J | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 1.1 V | 1.42 V | 0.154 in 3.9 mm | |
Nisshinbo Micro Devices Inc. | 6-UFDFN Exposed Pad | Over Current Over Temperature | 70 db | Positive | 90 çA | 6.5 V | Enable | DFN(PL)1820-6 | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 1.25 V | 1.38 V | ||
 Nisshinbo Micro Devices Inc. | SOT-89-5/6 | Over Current Over Temperature | 70 db | Positive | 90 çA | 6.5 V | Enable | SOT-89-5 | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 1.8 V | 1.1 V | ||
Nisshinbo Micro Devices Inc. | 6-UFDFN Exposed Pad | Over Current Over Temperature | 70 db | Positive | 90 çA | 6.5 V | Enable | DFN(PL)1820-6 | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 0.9 V | 1.5 V | ||
Nisshinbo Micro Devices Inc. | 6-UFDFN Exposed Pad | Over Current Over Temperature | 70 db | Positive | 90 çA | 6.5 V | Enable | DFN(PL)1820-6 | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 3.1 V | 0.75 V | ||
Nisshinbo Micro Devices Inc. | 4 Leads + 2 Fins 6-SOIC Variation | Over Current Over Temperature | 60 dB | Positive | 90 çA | 6.5 V | Enable | 6-HSOP-J | 1 | 85 C | -40 ¯C | 1 A | Surface Mount | 5 V | 0.65 V | 0.154 in 3.9 mm |
