LPPB092 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN HDR 18POS 0.05 GOLD PCB
| Part | Contact Shape | Insulation Material | Contact Finish Thickness - Post | Contact Material | Number of Positions Loaded | Contact Finish Thickness - Mating | Fastening Type | Number of Positions | Pitch - Mating | Pitch - Mating | Number of Rows [custom] | Mounting Type | Contact Finish - Mating | Termination | Contact Type | Insulation Height | Insulation Height | Connector Type | Row Spacing - Mating | Row Spacing - Mating | Insulation Color | Contact Finish - Post | Contact Length - Post | Contact Length - Post | Operating Temperature [Max] | Operating Temperature [Min] | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Square | Liquid Crystal Polymer (LCP) | Flash | Phosphor Bronze | All | Flash | Push-Pull | 18 | 1.27 mm | 0.05 in | 2 | Through Hole | Gold | Solder | Female Socket | 0.177 in | 4.5 mm | Header | 0.05 in | 1.27 mm | Black | Gold | 0.118 in | 3 mm | 125 °C | -40 C | UL94 V-0 |
