MCE10 Series
Manufacturer: XP Power
Beta
⌘K
AC/DC POWER MODULES 10W PCB MOUNT OPEN FRAME MEDICAL AC-DC POWER SUPPLY, SINGLE OUTPUT 48VDC 0.21A
| Part | Load Regulation | Line Regulation | Mounting Type | Approval Agency | Standard Number | Features | Voltage - Output 1 | Efficiency | Power (Watts) | Current - Output (Max) [Max] | Type | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Package / Case | Number of Outputs | Applications | Voltage - Input [Min] | Voltage - Input [Max] | Load Regulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 XP Power | ±5% | 1 % | Through Hole | CB CE TUV UKCA UL | 60601-1 | Universal Input | 48 V | 84 % | 10 W | 210 mA | Open Frame | 70 °C | -25 °C | 1.05 in | 22.4 mm | 26.7 mm | 48.3 mm | 1.9 " | 0.88 in | 4-DIP Module | 1 | Medical | 80 VAC | 264 VAC | |
XP Power | 1 % | Through Hole | CB CE TUV UKCA UL | 60601-1 | Universal Input | 3.3 V | 76 % | 7.92 W | 2.4 A | Open Frame | 70 °C | -25 °C | 1.05 in | 22.4 mm | 26.7 mm | 48.3 mm | 1.9 " | 0.88 in | 4-DIP Module | 1 | Medical | 80 VAC | 264 VAC | 3 % | |
 XP Power | ±5% | 1 % | Through Hole | CB CE TUV UKCA UL | 60601-1 | Universal Input | 15 V | 81 % | 10 W | 670 mA | Open Frame | 70 °C | -25 °C | 1.05 in | 22.4 mm | 26.7 mm | 48.3 mm | 1.9 " | 0.88 in | 4-DIP Module | 1 | Medical | 80 VAC | 264 VAC |
