857-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 60POS 0.156
| Part | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Material - Insulation | Card Type | Pitch | Pitch | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Contact Material | Read Out | Number of Rows [custom] | Mounting Type | Contact Type | Termination | Card Thickness [Max] | Card Thickness [Min] | Color | Termination Rows | Number of Positions | Number of Positions/Bay/Row | Number of Rows | Termination Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Dual | 2 | Through Hole | Semi Bellows | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 1 | 60 | 30 | |||||
 EDAC Inc. | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Single | Right Angle Through Hole | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 1 | 30 | 30 | 1 | |||||
 EDAC Inc. | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Single | Through Hole | Semi Bellows | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 1 | 30 | 30 | 1 | |||||
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Dual | 2 | Through Hole | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 30 | 15 | 2 | |||||||
 EDAC Inc. | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Gold | 125 °C | -40 C | Female | Copper Alloy | Dual | 2 | Board Edge Straddle Mount | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 30 | 15 | 2 | 0.25 Ám | 10 Áin | Card Extender | ||
 EDAC Inc. | Flush Mount M3 Threaded Insert Top Opening | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Gold | 125 °C | -40 C | Female | Copper Alloy | Dual | 2 | Through Hole | Semi Bellows | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 30 | 15 | 2 | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Flush Mount M3 Threaded Insert Top Opening | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Dual | 2 | Through Hole | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 1 | 60 | 30 | |||||||
 EDAC Inc. | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Single | Through Hole | Semi Bellows | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 1 | 30 | 30 | 1 | |||||
 EDAC Inc. | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Dual | 2 | Board Edge Straddle Mount | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 30 | 15 | 2 | Card Extender | ||||
 EDAC Inc. | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Tin | 125 °C | -40 C | Female | Copper Alloy | Dual | 2 | Through Hole | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 30 | 15 | 2 |
