3100-0 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN PIN RCPT
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Hole Diameter [diameter] | Mounting Hole Diameter [diameter] | Contact Finish Thickness | Contact Finish Thickness | Termination | Flange Diameter [diameter] | Flange Diameter [diameter] | Socket Depth [z] | Socket Depth [z] | Pin Hole Diameter [diameter] | Pin Hole Diameter [diameter] | Contact Finish | Accepts Pin Diameter [Max] | Accepts Pin Diameter [Min] | Accepts Pin Diameter [Max] | Accepts Pin Diameter [Min] | Length - Overall [x] | Length - Overall [x] | Contact Material | Tail Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | -55 C | 125 °C | 0.074 in | 1.88 mm | 0.25 Ám | 10 Áin | Solder | 0.09 in | 2.29 mm | 0.323 in | 8.2 mm | 1.63 mm | 0.064 in | Gold | 1.17 mm | 0.81 mm | 0.046 " | 0.032 " | 0.353 in | 8.97 mm | Beryllium Copper | No Tail |
 Mill-Max Manufacturing Corp. | -55 C | 125 °C | 0.074 in | 1.88 mm | 0.76 Ám | 30 Áin | Solder | 0.09 in | 2.29 mm | 0.323 in | 8.2 mm | 1.63 mm | 0.064 in | Gold | 1.17 mm | 0.81 mm | 0.046 " | 0.032 " | 0.353 in | 8.97 mm | Beryllium Copper | No Tail |
Mill-Max Manufacturing Corp. | -55 C | 125 °C | 0.074 in | 1.88 mm | 0.25 Ám | 10 Áin | Solder | 0.09 in | 2.29 mm | 0.323 in | 8.2 mm | 1.63 mm | 0.064 in | Gold | 1.17 mm | 0.81 mm | 0.046 " | 0.032 " | 0.353 in | 8.97 mm | Beryllium Copper | No Tail |
Mill-Max Manufacturing Corp. | -55 C | 125 °C | 0.074 in | 1.88 mm | 0.76 Ám | 30 Áin | Solder | 0.09 in | 2.29 mm | 0.323 in | 8.2 mm | 1.63 mm | 0.064 in | Gold | 1.17 mm | 0.81 mm | 0.046 " | 0.032 " | 0.353 in | 8.97 mm | Beryllium Copper | No Tail |
Mill-Max Manufacturing Corp. | -55 C | 125 °C | 0.074 in | 1.88 mm | 0.25 Ám | 10 Áin | Solder | 0.09 in | 2.29 mm | 0.323 in | 8.2 mm | 1.63 mm | 0.064 in | Gold | 1.17 mm | 0.81 mm | 0.046 " | 0.032 " | 0.353 in | 8.97 mm | Beryllium Copper | No Tail |
 Mill-Max Manufacturing Corp. | -55 C | 125 °C | 0.074 in | 1.88 mm | 0.76 Ám | 30 Áin | Solder | 0.09 in | 2.29 mm | 0.323 in | 8.2 mm | 1.63 mm | 0.064 in | Gold | 1.17 mm | 0.81 mm | 0.046 " | 0.032 " | 0.353 in | 8.97 mm | Beryllium Copper | No Tail |
 Mill-Max Manufacturing Corp. | -55 C | 125 °C | 0.074 in | 1.88 mm | 5.08 Ám | 200 Áin | Solder | 0.09 in | 2.29 mm | 0.323 in | 8.2 mm | 1.63 mm | 0.064 in | Tin | 1.17 mm | 0.81 mm | 0.046 " | 0.032 " | 0.353 in | 8.97 mm | Beryllium Copper | No Tail |
