GTT38A Series

Catalog

TFT DISPLAYS & ACCESSORIES 3.8"TFT RESIST TOUCH TTL, 9-35V

Part	Dot Pitch [x]	Dot Pitch [y]	Backlight	Diagonal Screen Size [custom]	Diagonal Screen Size [custom]	Display Type	Interface	Viewing Area [x]	Viewing Area [y]	Display Mode	Touchscreen	Graphics Color	Dot Pixels [y]	Dot Pixels [x]
Matrix Orbital GTT38A-TPR-BLH-B0-H1-CS-VPT	0.2 mm	0.2 mm	LED - White	96.52 mm	3.8 in	TFT - Color	I2C RS-232	98.04 mm	26.3 mm	Transmissive	Resistive	Blue Green Red	116	480
Matrix Orbital GTT38A-TPR-BLH-B0-H1-CT-V5	0.2 mm	0.2 mm	LED - White	96.52 mm	3.8 in	TFT - Color	I2C TTL	98.04 mm	26.3 mm	Transmissive	Resistive	Blue Green Red	116	480
Matrix Orbital GTT38A-TPR-BLH-B0-H1-CU-V5	0.2 mm	0.2 mm	LED - White	96.52 mm	3.8 in	TFT - Color	I2C USB	98.04 mm	26.3 mm	Transmissive	Resistive	Blue Green Red	116	480
Matrix Orbital GTT38A-TPR-BLH-B0-H1-CU-VPT	0.2 mm	0.2 mm	LED - White	96.52 mm	3.8 in	TFT - Color	USB	98.04 mm	26.3 mm		Resistive	Blue Green Red	116	480
Matrix Orbital GTT38A-TPR-BLH-B0-H1-CT-VPT	0.2 mm	0.2 mm	LED - White	96.52 mm	3.8 in	TFT - Color	I2C TTL	98.04 mm	26.3 mm	Transmissive	Resistive	Blue Green Red	116	480
Matrix Orbital GTT38A-TPR-BLH-B0-H1-C4-VPT
Matrix Orbital GTT38A-TPR-BLH-B0-H1-C4-V5
Matrix Orbital GTT38A-TPR-BLH-B0-H1-CS-V5	0.2 mm	0.2 mm	LED - White	96.52 mm	3.8 in	TFT - Color	I2C RS-232	98.04 mm	26.3 mm	Transmissive	Resistive	Blue Green Red	116	480
