5110/50C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 50 COND 22AWG BLACK 1000'
| Part | Shield Coverage | Shield Material | Operating Temperature [Min] | Operating Temperature [Max] | Features | Number of Conductors | Shield Type | Jacket (Insulation) Material | Conductor Material | Length | Length | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Strand [custom] | Conductor Strand [custom] | Cable Type | Voltage | Conductor Insulation | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Ratings | Usage | Wire Gauge | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 70 % 100 % | Copper Tinned Suprashield® | -35 °C | 105 ░C | Biological Compatibility Drain Wire Rip Cord | 50 | Braid Foil | Poly-Vinyl Chloride (PVC) | Copper Tinned | 304.8 m | 1000 ft | Black | 0.506 in | 12.85 mm | 30 AWG | 7 | Multi-Conductor | 300 VDC | Poly-Vinyl Chloride (PVC) | 0.813 mm | 0.032 in | ISO 10993 UL Style 2464 | Communication Control | 22 AWG | ||
 ALPHA WIRE | 70 % 100 % | Copper Tinned Suprashield® | -35 °C | 105 ░C | Biological Compatibility Drain Wire Rip Cord | 50 | Braid Foil | Poly-Vinyl Chloride (PVC) | Copper Tinned | Slate | 0.506 in | 12.85 mm | 30 AWG | 7 | Multi-Conductor | 300 VDC | Poly-Vinyl Chloride (PVC) | 0.813 mm | 0.032 in | ISO 10993 UL Style 2464 | Communication Control | 22 AWG | 100 ft | 30.5 m | ||
ALPHA WIRE | 70 % 100 % | Copper Tinned Suprashield® | -35 °C | 105 ░C | Biological Compatibility Drain Wire Rip Cord | 50 | Braid Foil | Poly-Vinyl Chloride (PVC) | Copper Tinned | Slate | 0.506 in | 12.85 mm | 30 AWG | 7 | Multi-Conductor | 300 VDC | Poly-Vinyl Chloride (PVC) | 0.813 mm | 0.032 in | ISO 10993 UL Style 2464 | Communication Control | 22 AWG |
