845-046 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 46POS 0.100
...
| Part | Termination Rows | Material - Insulation | Termination | Read Out | Gender | Color | Number of Positions/Bay/Row | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Mounting Type | Contact Type | Card Type | Pitch | Pitch | Number of Rows | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Termination Rows [custom] | Features | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | Single | Female | Green | 46 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Copper Alloy | Right Angle Through Hole | Cantilever | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Gold | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | Single | Female | Green | 46 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Through Hole | Cantilever | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Gold | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | Dual | Female | Green | 23 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | 2.95 mm | Copper Alloy | Board Edge Straddle Mount | Cantilever | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Gold | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 2 | Card Extender | 2 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Wire Wrap | Dual | Female | Green | 23 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Copper Alloy | Through Hole | Cantilever | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Gold | 0.25 Ám | 10 Áin | 2 | 2 | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | Single | Female | Green | 46 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.116 " | 2.95 mm | Copper Alloy | Right Angle Through Hole | Cantilever | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Gold | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Single | Female | Green | 46 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Through Hole | Cantilever | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Gold | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | Dual | Female | Green | 23 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Through Hole | Cantilever | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Gold | 0.25 Ám | 10 Áin | 2 | 2 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | Dual | Female | Green | 23 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Copper Alloy | Through Hole | Cantilever | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Gold | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Solder | Dual | Female | Green | 23 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Copper Alloy | Right Angle Through Hole | Cantilever | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Gold | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 2 | 2 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | Single | Female | Green | 46 | 46 | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Copper Alloy | Through Hole | Cantilever | Non Specified - Single Edge | 0.1 " | 2.54 mm | 1 | Gold | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded |
