2127Z Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2COND 16AWG BLK SHLD
| Part | Shield Material | Shield Coverage | Voltage | Features | Conductor Insulation | Conductor Insulation | Number of Conductors | Wire Gauge | Ratings | Shield Type | Operating Temperature [Min] | Operating Temperature [Max] | Jacket Color | Jacket (Insulation) Material | Conductor Material | Cable Type | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | 600 V | Drain Wire Oil Resistant Rip Cord UV Resistant | Polyolefin | PO | 2 | 16 AWG | UL Style TC | Foil | -20 ░C | 90 °C | Black | Low Smoke Zero Halogen (LSZH) | Copper Tinned | Multi-Conductor | 7 | 24 AWG | 9.27 mm | 0.365 in |
