L6R250 Series
Manufacturer: Tri-Mag, LLC
Beta
⌘K
AC/DC DESKTOP ADAPTER 12V 240W
| Part | Weight [custom] | Weight [custom] | Power (Watts) | Form | Input Type | Efficiency | Output Connector | Output Connector | Approval Agency | Cord Length | Cord Length | Input Connector | Voltage - Output | Current - Output (Max) [Max] | Applications | No Load Power Consumption | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Region Utilized | Standard Number | Voltage - Input [Max] | Voltage - Input [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Tri-Mag, LLC | 2.3 lbs | 1 kg | 240 Watts | Desktop (Class I) | Cord (Sold Separately) | CoC Tier 2 Level VI | Rectangular | 6 Position | CE cULus EN FCC TUV | 1.2 m | 47.2 in | IEC 320-C6 | 12 V | 20 A | ITE (Commercial) | 150 mW | 40 °C | 0 °C | 43.6 mm | 1.71 in | 8.03 in | 94 mm | 204 mm | 3.7 in | International | 62368-1 | 264 VAC | 90 VAC |
Tri-Mag, LLC | 2.3 lbs | 1 kg | 250 W | Desktop (Class I) | Cord (Sold Separately) | CoC Tier 2 Level VI | Rectangular | 6 Position | CE cULus EN FCC TUV | 1.5 m | 59 in | IEC 320-C6 | 48 V | 5.2 A | ITE (Commercial) | 150 mW | 40 °C | 0 °C | 43.6 mm | 1.71 in | 8.03 in | 94 mm | 204 mm | 3.7 in | International | 62368-1 | 264 VAC | 90 VAC |
 Tri-Mag, LLC | 250 W | Desktop (Class I) | Cord (Sold Separately) | Level VI | Rectangular | 6 Position | CE cULus EN FCC TUV | 1.5 m | 59 in | IEC 320-C14 | 48 V | 5.21 A | Medical | 150 mW | 40 °C | 0 °C | 43.5 mm | 1.71 in | 8.03 in | 94 mm | 204 mm | 3.7 in | International | 60601-1 | 264 VAC | 90 VAC | ||
Tri-Mag, LLC | 2.3 lbs | 1 kg | 240 Watts | Desktop (Class I) | Cord (Sold Separately) | CoC Tier 2 Level VI | Rectangular | 6 Position | CE cULus EN FCC TUV | 1.2 m | 47.2 in | IEC 320-C14 | 12 V | 20 A | ITE (Commercial) | 150 mW | 40 °C | 0 °C | 43.6 mm | 1.71 in | 8.03 in | 94 mm | 204 mm | 3.7 in | International | 62368-1 | 264 VAC | 90 VAC |
Tri-Mag, LLC | 2.3 lbs | 1 kg | 250 W | Desktop (Class I) | Cord (Sold Separately) | CoC Tier 2 Level VI | Rectangular | 6 Position | CE cULus EN FCC TUV | 1.5 m | 59 in | IEC 320-C6 | 19 V | 13.2 A | ITE (Commercial) | 150 mW | 40 °C | 0 °C | 43.6 mm | 1.71 in | 8.03 in | 94 mm | 204 mm | 3.7 in | International | 62368-1 | 264 VAC | 90 VAC |
Tri-Mag, LLC | 2.3 lbs | 1 kg | 250 W | Desktop (Class I) | Cord (Sold Separately) | CoC Tier 2 Level VI | Rectangular | 6 Position | CE cULus EN FCC TUV | 1.5 m | 59 in | IEC 320-C6 | 24 V | 10.42 A | ITE (Commercial) | 150 mW | 40 °C | 0 °C | 43.6 mm | 1.71 in | 8.03 in | 94 mm | 204 mm | 3.7 in | International | 62368-1 | 264 VAC | 90 VAC |
