IRM-20 Series

Catalog

AC/DC CONVERTER 12V 22W

Part	Voltage - Input [Min]	Voltage - Input [Max]	Load Regulation	Line Regulation	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Power (Watts)	Approval Agency	Number of Outputs	Current - Output (Max) [Max]	Mounting Type	Features	Voltage - Output 1	Applications	Type	Efficiency	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Load Regulation
MEAN WELL USA Inc. IRM-20-12	85 VAC 120 VDC	264 VAC 305 VAC 370 VDC 430 VDC	0.5 %	0.3 %	1.07 in	0.94 "	2.06 "	27.2 mm	52.4 mm	24 mm	22 W	CB CE cURus TUV	1	1.8 A	Through Hole	Universal Input	12 V	ITE (Commercial)	Enclosed	84 %	4-DIP Module	-30 °C	70 °C
MEAN WELL USA Inc. IRM-20-15	85 VAC 120 VDC	264 VAC 305 VAC 370 VDC 430 VDC	0.5 %	0.3 %	1.07 in	0.94 "	2.06 "	27.2 mm	52.4 mm	24 mm	21 W	CB CE cURus TUV	1	1.4 A	Through Hole	Universal Input	15 V	ITE (Commercial)	Enclosed	84 %	4-DIP Module	-30 °C	70 °C
MEAN WELL USA Inc. IRM-20-5	85 VAC 120 VDC	264 VAC 305 VAC 370 VDC 430 VDC		0.5 %	1.07 in	0.94 "	2.06 "	27.2 mm	52.4 mm	24 mm	20 W	CB CE cURus TUV	1	4 A	Through Hole	Universal Input	5 V	ITE (Commercial)	Enclosed	79 %	4-DIP Module	-30 °C	70 °C	±1%
MEAN WELL USA Inc. IRM-20-3.3	85 VAC 120 VDC	264 VAC 305 VAC 370 VDC 430 VDC		0.5 %	1.07 in	0.94 "	2.06 "	27.2 mm	52.4 mm	24 mm	15 W	CB CE cURus TUV	1	4.5 A	Through Hole	Universal Input	3.3 V	ITE (Commercial)	Enclosed	76 %	4-DIP Module	-30 °C	70 °C	±1%
