VF-D250 Series
Manufacturer: CUI Inc.
Beta
⌘K
AC/DC CONVERTER 12V 24V 250W
| Part | Type | Approval Agency | Standard Number | Voltage - Output 1 | Voltage - Isolation | Number of Outputs | Efficiency | Voltage - Input [Max] | Voltage - Input [Min] | Current - Output 2 | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Voltage - Output 2 | Current - Output 1 | Features | Power (Watts) | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | Open Frame | CB Scheme CCC EN IEC SIQ TUV UL | 55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 | 12 V | 3000 V | 2 | 70 % | 264 VAC | 90 VAC | 6 A | Chassis Mount | 70 °C | 0 °C | ITE (Commercial) | 24 V | 12 A | Adjustable Output Remote On/Off | 250 W | 5 " | 38.1 mm | 81.3 mm | 3.2 " | 1.5 in | 127 mm |
 CUI Inc. | Enclosed | CB Scheme EN IEC SIQ TUV UL | 55024 55032 Class B 60950-1 61000-3-2 61000-3-3 62368-1 | 12 V | 3000 V | 2 | 70 % | 264 VAC | 90 VAC | 6 A | Chassis Mount | 70 °C | 0 °C | ITE (Commercial) | 24 V | 12 A | Adjustable Output Remote On/Off | 250 W | 5 " | 38.1 mm | 81.3 mm | 3.2 " | 1.5 in | 127 mm |
