RC211 Series

Catalog

SWITCH ROCKER SPDT 16A 125V

Part	Electrical Life	Actuator Marking	Mounting Type	Switch Function	Approval Agency	Current Rating (Amps)	Color - Actuator/Cap	Voltage Rating - AC	Circuit	Termination Style	Operating Temperature [Max]	Actuator Type	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]
Carling Technologies RC211-RR-B-0-N	100000 Cycles	No Marking	Panel Mount Snap-In	On-Off-On	BEAB CSA DEMKO FIMKO NEMKO SEMKO SEV TUV UL VDE	16 A	Black	125 V	SPDT	Quick Connect - 0.250" (6.3mm)	85 °C	Concave (Curved)	13.97 mm	28.58 mm
Carling Technologies RC211-RW-B-0-N	100000 Cycles	No Marking	Panel Mount Snap-In	On-Off-On	BEAB CSA DEMKO FIMKO NEMKO SEMKO SEV TUV UL VDE	16 A	White	125 V	SPDT	Quick Connect - 0.250" (6.3mm)	85 °C	Concave (Curved)	13.97 mm	28.58 mm
Carling Technologies RC211-RB-B-0-N	100000 Cycles	No Marking	Panel Mount Snap-In	On-Off-On	BEAB CSA DEMKO FIMKO NEMKO SEMKO SEV TUV UL VDE	16 A	Black	125 V	SPDT	Quick Connect - 0.250" (6.3mm)	85 °C	Concave (Curved)	13.97 mm	28.58 mm
