BZ-7RW Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION SPDT 15A 125V
| Part | Current Rating (Amps) | Voltage Rating - DC | Overtravel | Overtravel | Termination Style | Ingress Protection | Differential Travel | Differential Travel | Operating Temperature [Max] | Operating Temperature [Min] | Circuit | Voltage Rating - AC | Actuator Type | Mechanical Life | Operating Position | Operating Position | Mounting Type | Operating Force | Switch Function | Overtravel | Release Force |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | 15 A 500 mA | 125 VDC | 0.094 in | 2.4 mm | Screw Terminal | IP64 - Dust Tight Water Resistant | 0.05 in | 1.3 mm | 85 °C | -55 °C | SPDT | 125 V | Lever Roller | 20000000 Cycles | 30.2 mm | 1.188 in | Chassis Mount | 198 gf | On-Mom | ||
 Honeywell Sensing and Productivity Solutions | 10 A 500 mA | 125 VDC | 0.172 in | Screw Terminal | Splash Proof | 0.1 in | 2.54 mm | 85 °C | -55 °C | SPDT | 125 V | Lever Straight | 20000000 Cycles | 19.1 mm | 0.75 " | Chassis Mount | 120 gf | On-Mom | 4.4 mm | 21 gf |
